Phanteks PH-F140M25 140mm PWM Case Fan - Black

Phanteks PH-F140M25 140mm PWM Case Fan - Black
Phanteks PH-F140M25 140mm PWM Case Fan - Black
Phanteks PH-F140M25 140mm PWM Case Fan - Black
Phanteks PH-F140M25 140mm PWM Case Fan - Black
Phanteks PH-F140M25 140mm PWM Case Fan - Black
Phanteks PH-F140M25 140mm PWM Case Fan - Black
Phanteks PH-F140M25 140mm PWM Case Fan - Black
Phanteks PH-F140M25 140mm PWM Case Fan - Black
Phanteks PH-F140M25 140mm PWM Case Fan - Black
Phanteks PH-F140M25 140mm PWM Case Fan - Black
R563
The Phanteks PH-F140M25 is a high-performance 140mm case fan designed for efficient cooling and quiet operation. Featuring a 4-pin PWM connector for automatic speed control, this fan delivers airflow from 23.6 to 82.1 CFM with noise levels as low as 18 dBA. The advanced UFB (Updraft Floating Balance... Read More
Stock 100 Code 3016429 Brand PHANTEKS Model PH-F140M25_DRGB_PWM_WT01 Warranty 2 Years

Shipping & Returns

Estimated delivery Thursday, October 1
You will be kept updated through our detailed tracking system
Payment options
EFTPayFastBank CardSnapScanZapperGoogle PayApple PayMobicredMoreTymePay on Arrival

The Phanteks PH-F140M25 is a high-performance 140mm case fan designed for efficient cooling and quiet operation. Featuring a 4-pin PWM connector for automatic speed control, this fan delivers airflow from 23.6 to 82.1 CFM with noise levels as low as 18 dBA. The advanced UFB (Updraft Floating Balance) bearing ensures long-lasting durability with an MTBF of over 150,000 hours.

Advantages

Optimized for both airflow and static pressure, the M25 series excels in various configurations. The 9-blade design and square frame minimize turbulence, while the included mounting screws make installation straightforward. Ideal for PC enthusiasts seeking reliable cooling without excessive noise.

Suitable for

  • PC case cooling
  • Radiator cooling
  • Silent builds

Key specifications

  • Fan Size: 140 mm
  • Speed: 500 - 1500 RPM
  • Airflow: 23.6 - 82.1 CFM
  • Static Pressure: 0.39 - 1.52 mmH2O
  • Noise Level: 18 - 25 dBA
  • Bearing: UFB Bearing
  • Connector: 4-pin PWM
  • Voltage: DC 12V
  • Current: 0.15 A
  • Power Consumption: 1.8 W
  • MTBF: >150,000 hours
  • Color: Black
  • LED: No
  • Blades: 9
  • Frame: Square
  • Cable Length: 500 mm

Recommendations

For optimal performance, pair this fan with a PWM-capable motherboard or fan controller. Suitable for use as a case intake or exhaust fan.

Specifications
Airflow
23.6 - 82.1 CFM
Bearing type
UFB Bearing
Brand
Phanteks
Cable length
500 mm
Category
Case Fans
EAN
886523002512
Fan connector
4-pin PWM
Fan diameter
140 mm
Maximum air pressure
1.52 mmH2O
Maximum airflow
82.1 CFM
Mean time between failures (MTBF)
150000 hours
Model
PH-F140M25_DRGB_PWM_WT01
MPN
PH-F140M25_DRGB_PWM_WT01
Noise level (high speed)
25 dBA
Number of fan blades
9
Number of screws
4
Power consumption (typical)
1.8 W
Product colour
Black
Pulse-width modulation (PWM) support
Yes
Rated current
0.15 A
Rated voltage
12 V
Rotational speed (max)
1500 RPM
Screws included
Yes
Type
Fan
Weight
0.18 kg
