OMNITRONIC MTC-3204DSP 4-Channel Power Amplifier with DSP, 4 x 800 W at 4 Ohm, Class D, 1U Rack Mount 10452431

Delivering a formidable 4 x 800 W RMS at 4 ohms from a 1U chassis, the OMNITRONIC MTC-3204DSP redefines power density for professional sound reinforcement. This four-channel Class D amplifier integrates a high-resolution 24-bit DSP engine, enabling precise system tuning without external processors. Ideal for touring racks, fixed installations, and multi-zone audio systems, it combines raw output with advanced loudspeaker management in a single, space-efficient unit.

Overview

The MTC-3204DSP is engineered for demanding live sound and installation environments. Each of its four channels delivers 800 W RMS at 4 ohms or 450 W RMS at 8 ohms, with bridge mode offering a massive 1600 W RMS per channel pair at 8 ohms. The integrated DSP operates at 96 kHz with 24-bit AD/DA conversion, providing crossover, parametric EQ, delay, limiter, gain, and phase controls. A USB port allows connection to a PC for deep editing via software, while the front panel offers essential status LEDs. Inputs are balanced XLR, and outputs use Neutrik Speakon-compatible connectors for reliable, high-current connections.

What stands out

• Exceptional power-to-size ratio: 4 x 800 W at 4 ohms in only 1U rack space.
• Integrated 24-bit DSP with 96 kHz sampling for studio-grade audio processing.
• Flexible configuration: 4-channel, 2-channel bridged, or mixed operation.
• Comprehensive protection circuitry including overload, short circuit, DC, overheating, and soft start.
• Universal power supply (100-240 V AC) for worldwide use without external transformers.

Technical details

• Amplifier class: Class D (high efficiency, low heat)
• Power output (RMS): 4 x 800 W @ 4 Ω, 4 x 450 W @ 8 Ω, 2 x 1600 W @ 8 Ω bridged
• DSP: 24-bit, 96 kHz sampling, functions: crossover, parametric EQ, delay, limiter, gain, phase
• Frequency response: 20 Hz – 20 kHz
• Signal-to-noise ratio: >100 dB
• Total harmonic distortion: <0.05%
• Input connectors: 4 x XLR (balanced)
• Output connectors: 4 x Speaker Twist (Neutrik Speakon compatible)
• Input sensitivity: 1.2 V
• Input impedance: 20 kΩ (balanced)
• Control interface: USB (PC software), Ethernet (optional)
• Rack size: 1U (19-inch)
• Protection: overload, short circuit, DC, overheating, soft start
• Power supply: 100-240 V AC, 50/60 Hz

Our verdict

For professionals seeking maximum channel count and DSP control in minimal rack space, the MTC-3204DSP is a compelling solution. Its robust power output and comprehensive processing make it suitable for everything from compact line arrays to multi-zone installations. The universal power supply and efficient Class D design add practical value for touring and fixed applications alike.
