Neomounts NS-EP100BLACK Extension pole TV ceiling mount - h 107,5 cm

The Neomounts NS-EP100BLACK is an extension pole designed to increase the height of compatible ceiling mounts by 107.5 cm. It fits as an extra extension for ceiling mount models NM-C440BLACK, NM-C440DBLACK, FPMA-C340BLACK and FPMA-C340DBLACK and is intended for pole clamp mounting. The connector has a width and depth of 52 mm, supports a minimum pole diameter of 25.4 mm and comes in a black finish.

Advantages

This extension tube provides a straightforward way to increase mounting height without replacing the original ceiling mount. It is lightweight at 1.86 kg, supports up to 100 kg load capacity and ships in compact packaging (1000 x 60 x 60 mm) for easy handling and storage.

Suitable for

• Extending the height of Neomounts ceiling mounts (NM-C440BLACK, NM-C440DBLACK, FPMA-C340BLACK, FPMA-C340DBLACK)
• Installations that require an additional 107.5 cm of pole length
• Displays or equipment that mount to a pole clamp with minimum 25.4 mm diameter

Key specifications

• Model: NS-EP100BLACK
• Height (extension): 1075 mm (107.5 cm)
• Width x Depth: 52 mm x 52 mm
• Minimum pole diameter supported: 25.4 mm
• Maximum weight capacity: 100 kg
• Weight: 1.86 kg
• Colour: Black
• Package dimensions: 1000 x 60 x 60 mm
• EAN: 8717371448400

How to use

Remove any safety covers from the existing ceiling pole and align the NS-EP100BLACK extension with the pole clamp of the compatible ceiling mount. Secure the extension according to the mount manufacturer’s instructions, ensuring the connection is tight and properly seated. After installation, verify that the combined assembly is stable and that the total load does not exceed the specified 100 kg capacity.

Recommendations

Use this extension only with the specified Neomounts ceiling mount models and ensure the pole clamp diameter is compatible (minimum 25.4 mm). Do not exceed the maximum weight capacity. Check all fastenings after installation and periodically during use.
