MSI PRO B760M-P DDR4 Micro-ATX Motherboard, Intel B760, LGA 1700, DDR4, PCIe 4.0, Wi-Fi 6E, 2.5G LAN

The MSI PRO B760M-P DDR4 is a reliable and feature-rich Micro-ATX motherboard built on the Intel B760 chipset. Designed for 12th and 13th Gen Intel Core processors, it offers a solid foundation for business and productivity builds. With support for DDR4 memory, PCIe 4.0, and integrated Wi-Fi 6E, this motherboard delivers stable performance and modern connectivity.

Advantages

Stable power delivery with 12+1+1 Duet Rail VRM design, ensuring reliable performance under load. Dual M.2 slots with PCIe 4.0 x4 support for fast storage. Integrated Intel Wi-Fi 6E and Bluetooth 5.3 for wireless connectivity. 2.5G LAN for high-speed wired networking. Comprehensive rear I/O including USB 3.2 Gen 2 Type-C and HDMI 2.1/DisplayPort 1.4 outputs.

Suitable for

• Business and office PCs
• Home theater and multimedia systems
• Entry-level to mid-range gaming builds
• Content creation workstations

Key specifications

• Chipset: Intel B760
• CPU Socket: LGA 1700
• Memory: 4x DDR4 DIMM, up to 128GB, up to 5333+ MHz (OC)
• Form Factor: Micro-ATX
• Storage: 2x M.2 PCIe 4.0 x4, 4x SATA 6Gb/s
• LAN: Realtek RTL8125BG 2.5Gbps
• Wireless: Intel Wi-Fi 6E, Bluetooth 5.3
• Audio: Realtek ALC897, 7.1-channel HD Audio
• Rear USB: 1x USB 3.2 Gen 2 Type-C, 3x USB 3.2 Gen 1 Type-A, 2x USB 2.0
• Video Outputs: 1x HDMI 2.1, 1x DisplayPort 1.4
• Power Connectors: 1x 24-pin ATX, 1x 8-pin EPS

Recommendations

For a balanced and future-proof build, pair this motherboard with an Intel Core i5-13400 processor and DDR4-3200 memory. The integrated Wi-Fi 6E ensures fast wireless connectivity, while the 2.5G LAN is ideal for NAS or high-speed internet.
