MikroTik XS+85LC01D SFP28 Module 25 Gbps LC Duplex Single-mode 10 km

The MikroTik XS+85LC01D is a high-performance SFP28 transceiver module designed for 25 Gigabit Ethernet connectivity over single-mode fiber. It supports data rates of 25 Gbps and is backward compatible with 10 Gbps networks, making it a versatile solution for data centers and enterprise networking. With a wavelength of 1310 nm and a maximum transmission distance of 10 km, this module ensures reliable long-distance connections. The LC duplex connector and hot-swappable design facilitate easy installation and maintenance. Compliant with IEEE 802.3by (25GBASE-LR) and SFF standards, it delivers low power consumption (<1.5 W) and supports DDM/DOM for real-time monitoring.

Advantages

High-speed 25 Gbps connectivity with backward compatibility to 10 Gbps; long reach up to 10 km over single-mode fiber; low power consumption and hot-swappable for minimal downtime; DDM/DOM support for proactive network management.

Suitable for

• Data center interconnects
• Enterprise network backbone
• High-bandwidth server connections
• Telecommunications infrastructure

Key specifications

• Module Type: SFP28
• Data Rate: 25 Gbps (backward compatible to 10 Gbps)
• Wavelength: 1310 nm
• Max Distance: 10 km
• Fiber Type: Single-mode (OS2)
• Connector: LC Duplex
• DDM/DOM: Yes
• Operating Temperature: 0°C to 70°C
• Power Consumption: <1.5 W
• Standards: IEEE 802.3by, SFF-8472, SFF-8431, SFF-8432
• Hot-Swappable: Yes
• Voltage: 3.3V

Recommendations

For optimal performance, use with MikroTik devices equipped with SFP28/SFP+/SFP ports. Ensure single-mode fiber (OS2) with LC connectors is used. This module is ideal for upgrading existing 10 GbE links to 25 GbE without replacing the entire infrastructure.
