MIKROTIK Rb1100ahx4 Dude Edition With Routeros L6, Indoor Case

MIKROTIK Rb1100ahx4 Dude Edition With Routeros L6, Indoor Case

RB1100AHx4 Dude Edition uses a new four-core Cortex A15 chip. The chip is clocked at 1.4GHz, which provides maximum throughput up to 7.5Gbit additionally supports IPsec hardware acceleration and is faster than any other RouterBOARD device. The device has several quick connectors for storage (two SATA and two M.2) to use the Dude database, cache or other storage. It contains an M.2 drive with 60 GB and comes with a Dude package that has already been installed for full functionality. The device has two IEC emergency power connectors, supports passive or 802.3at/af PoE input and has a DC telecommunications connector for -48V DC. It uses passive cooling.

Specifications

• Depth: 47 mm
• Height: 148 mm
• Operating temperature (T-T): -40 - 70 °C
• Product colour: Silver
• Width: 444 mm
• Harmonized System (HS) code: 85176990
• Ethernet LAN: Yes
• Ethernet LAN data rates: 10,100,1000 Mbit/s
• Cables included: AC
• Built-in processor: Yes
• Processor frequency: 1400 MHz
• Internal storage capacity: 60 GB
• Operating system installed: RouterOS
• Ethernet LAN (RJ-45) ports: 13
• Power consumption (typical): 25 W
• LED indicators: Yes
• RS-232 ports: 1
• Power source type: DC, PoE
• Processor model: Annapurna Labs Alpine AL21400
• Processor cores: 4

Genuine Mikrotik product — MPN: RB1100DX4 · EAN: 4752224002648.
