Märklin 60667 Digital Central Station DCC, MM

Model railway enthusiasts operating complex layouts need a central command that unifies control of locomotives, accessories, and routes. The Märklin 60667 Digital Central Station DCC, MM serves as the command hub for your layout, supporting Märklin Motorola, DCC, and mfx protocols. Its high-resolution colour touch screen and two integrated rotary speed controllers provide direct, tactile operation, while the built-in track diagram control panel gives you a clear overview of your entire railway network.

Key specifications

• Supported protocols: Märklin Motorola (MM), DCC, mfx
• Display: High-resolution colour touch screen
• Control: 2 integrated rotary speed controllers
• Max. output current: 5 A (requires external power supply)
• Locomotive functions: up to 32 per locomotive
• Accessory addresses: up to 320 K83/K84
• Routes: up to 2048 programmable
• Interfaces: 2x USB Host, 1x USB Device, 1x LAN, 1x S88 feedback, 2x Booster connections
• Memory expansion: SD card slot
• Integrated Märklin Digital Locomotive Database
• Integrated web server for remote control
• Power supply: external 18V DC (e.g., 60061/60101, sold separately)

Why choose it

This central station consolidates control of your entire layout into one intuitive device. The touch screen and rotary controllers allow quick adjustments, while the extensive database and track diagram simplify management of even large fleets. Support for multiple protocols ensures compatibility with a wide range of locomotives and decoders.

Ideal use cases

• Large home layouts with mixed Märklin and DCC equipment
• Club layouts requiring multi-user operation via network
• Automated operation with routes and feedback modules

Good to know

The central station requires an external 18V DC power supply, which is not included. Use a suitable Märklin transformer such as 60061 or 60101 to power the station and connected boosters.
