LogiLink PCI Express USB 3.2 Card, 5 Gbps, 2 External + 3 Internal USB-A Ports

Upgrade your desktop PC with the LogiLink PCI Express USB 3.2 Card (PC0089). This high-performance expansion card adds five USB-A ports to your system, including two external ports for easy access and three internal ports for connecting front panel headers or internal devices. With USB 3.2 Gen 1 (5 Gbps) speed, it is ideal for fast data transfer, external storage, and peripherals.

Advantages

• Adds 5 USB-A ports (2 external, 1 internal, 2 via 19-pin header)
• SuperSpeed USB 3.2 Gen 1 with up to 5 Gbps data rate
• Backward compatible with USB 2.0 and USB 1.1 devices
• Plug & Play and hot-swap support for easy installation
• Powered via SATA 15-pin connector for reliable operation

Suitable for

• Desktop computers needing additional USB ports
• Connecting external hard drives, flash drives, and peripherals
• Internal USB connections for card readers or front panels
• Windows and Linux systems

Key specifications

• Host Interface: PCI Express x1 (PCIe 2.0)
• USB Standard: USB 3.2 Gen 1 (SuperSpeed)
• Max Data Transfer Rate: 5 Gbps
• External USB-A Ports: 2
• Internal USB-A Ports: 1
• Internal USB Header: 1x 19-pin USB 3.0 (supports 2 ports)
• Total USB Ports: 5
• Chipset: Renesas D720201
• Power Connector: 1x SATA 15-pin power
• Form Factor: Standard Profile PCIe Card
• Operating Systems: Windows 7/8/10/11, Linux

Recommendations

For best performance, connect USB 3.0/3.1/3.2 devices to the external ports. Ensure your power supply has a free SATA power connector. Compatible with standard PCIe x1, x4, x8, or x16 slots.
