LogiLink HDMI Connector Type A Male, Solder Termination, Metal Housing, Silver - Self-Assembly Connector for Custom HDMI Cables

Damaged HDMI cables often end up in the trash, but with the LogiLink CHP001 HDMI connector, you can repair them or build custom-length cables with professional results. This solder-type HDMI Type A male connector features a robust metal housing in silver and gold-plated contacts, ensuring reliable signal transmission for high-definition audio and video.

Who is it for

This connector is ideal for DIY enthusiasts, AV technicians, and anyone who needs to create or repair HDMI cables. Whether you're setting up a home theater, extending a cable run, or replacing a broken connector, this self-assembly solution gives you full control over cable length and quality.

Main features

• HDMI Type A male connector with 19 pins for full compatibility
• Solder termination for secure, durable connections
• Metal housing in silver for excellent shielding and durability
• Gold-plated contacts resist corrosion and ensure optimal signal transfer
• Supports HDMI versions 1.0 through 2.1 (physical compatibility)
• High-temperature resistant plastic insulator for safe soldering

Specifications

• Connector type: HDMI Type A male
• Number of pins: 19
• Termination: Solder
• Housing material: Metal
• Housing colour: Silver
• Contact plating: Gold
• Insulator material: High-temperature resistant plastic
• Mounting type: Cable mount
• Shielding: Yes (metal housing)
• Application: Self-assembly, cable repair, custom cable creation

Tips

When soldering, use a fine-tipped soldering iron and work quickly to avoid melting the insulator. Ensure the cable is properly prepared and the wires are tinned before soldering to the connector pins. After assembly, test the cable with a known working device to verify signal integrity.
