LOGILINK FA05SD1 Outdoor Fibre Optic Duplex SC Connector with Dust Cap – Multimode OM3/OM4, Aqua (10-Pack)

Rugged and dependable, the LOGILINK FA05SD1 is an outdoor-grade duplex SC connector for permanent fibre terminations. Its zirconia ceramic ferrules and precision-moulded polymer housing keep insertion loss below 0.3 dB, even when exposed to temperature swings. Each unit is supplied with a dust cap and comes in a handy 10-piece pack, making it straightforward to stock and deploy across multiple drop points.

Highlights

• SC duplex configuration for dual-fibre connections
• Optimised for multimode OM3 and OM4 networks, 50/125 µm
• Zirconia ceramic ferrule with PC polish for stable signal transfer
• Typical insertion loss under 0.3 dB; return loss above 30 dB
• High-grade polymer housing with aqua colour coding
• Includes protective dust caps; suitable for field installation

In daily use

Whether you are terminating a backbone cable in a data centre or preparing an outdoor distribution point, the FA05SD1 simplifies the process. The epoxy-and-polish installation method provides a secure, long-lasting bond to cables from 0.9 mm to 3.0 mm. After termination, the dust cap shields the polished ferrule from dust and mechanical damage, safeguarding signal integrity until the connector is mated. With a durability rating of more than 500 mating cycles, this connector is built to handle repeated reconnections without degradation.

Full specifications

• Product type: Outdoor fibre optic duplex SC connector with dust cap
• Connector type: SC Duplex
• Fibre mode: Multimode (OM3/OM4)
• Fibre core/cladding: 50/125 µm
• Compatible cable diameter: 0.9 mm, 2.0 mm, 3.0 mm
• Ferrule material: Zirconia ceramic
• Polishing type: PC (Physical Contact)
• Insertion loss: <0.3 dB typical
• Return loss: >30 dB typical
• Durability: >500 mating cycles
• Housing material: High-grade polymer
• Housing colour: Aqua
• Quantity per pack: 10 pieces
• Operating temperature: -20°C to +70°C
• Storage temperature: -40°C to +85°C
• Standards compliance: RoHS, REACH

Final note

The FA05SD1 is an excellent choice for installers who need a reliable, repeatable SC duplex termination for multimode fibre. With the dust cap included, it is ready to be integrated into your network infrastructure with confidence.
