Lightwin LWL DÄMPFUNG-09 LC/SPC 5 Fiber Optic Attenuator, LC/SPC Male to LC/SPC Female, 9 dB, Single-mode, Blue

In fiber optic networks, excessive optical power can overwhelm sensitive receivers, leading to signal distortion, bit errors, or even permanent damage to equipment. The Lightwin LWL DÄMPFUNG-09 LC/SPC 5 attenuator solves this by precisely reducing signal strength by 9 dB, ensuring optimal power levels for reliable data transmission.

Who is it for

This attenuator is ideal for network engineers, telecom technicians, and data center managers working with single-mode fiber systems. It is particularly useful during network testing, equipment calibration, or when connecting short-distance links where power levels exceed receiver specifications.

Main features

• Fixed 9 dB attenuation for precise signal control
• LC/SPC male to LC/SPC female connector configuration
• Single-mode fiber compatibility for long-haul and metro networks
• Super Physical Contact (SPC) polish for low insertion loss and high return loss
• Durable metal/plastic composite housing in blue for easy identification
• Wide operating temperature range for versatile deployment

Specifications

• Product Type: Fiber Optic Attenuator
• Connector Type (Input): LC/SPC Male
• Connector Type (Output): LC/SPC Female
• Attenuation Value: 9 dB
• Fiber Mode: Single-mode
• Polish Type: SPC (Super Physical Contact)
• Wavelength Range: 1310 nm / 1550 nm
• Return Loss: ≥ 50 dB
• Additional Insertion Loss: ≤ 0.2 dB
• Operating Temperature: -20°C to +70°C
• Storage Temperature: -40°C to +85°C
• Durability: > 500 Mating Cycles
• Housing Color: Blue
• Housing Material: Metal/Plastic Composite
• Compliance: RoHS, IEC 61754-20

Tips

Always clean the connector end faces before mating to ensure optimal performance. For accurate attenuation, verify the wavelength of your system matches the attenuator's specified range. Store in a protective cap when not in use to prevent contamination.
