LevelOne GEP-2652 network switch Managed L2 Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) Grey

LevelOne GEP-2652 network switch Managed L2 Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) Grey
LevelOne GEP-2652 network switch Managed L2 Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) Grey
LevelOne GEP-2652 network switch Managed L2 Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) Grey
LevelOne GEP-2652 network switch Managed L2 Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) Grey
LevelOne GEP-2652 network switch Managed L2 Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) Grey
LevelOne GEP-2652 network switch Managed L2 Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) Grey
LevelOne GEP-2652 network switch Managed L2 Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) Grey
LevelOne GEP-2652 network switch Managed L2 Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) Grey
LevelOne GEP-2652 network switch Managed L2 Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) Grey
LevelOne GEP-2652 network switch Managed L2 Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) Grey
R9,279
The LevelOne GEP-2652 is a web-smart switch with 24 PoE ports and 2 Gigabit SFP uplink ports. It provides Layer 2 switching features, a total PoE budget of 370W and support for IEEE 802.3af/at standards, enabling power delivery to PoE devices such as VoIP phones, wireless access points and network c... Read More
Stock 80 Code 111385 Brand LEVELONE Model GEP-2652 Warranty 2 Years

Shipping & Returns

Estimated delivery Monday, October 5
You will be kept updated through our detailed tracking system
Payment options
EFTPayFastBank CardSnapScanZapperGoogle PayApple PayMobicredMoreTymePay on Arrival

The LevelOne GEP-2652 is a web-smart switch with 24 PoE ports and 2 Gigabit SFP uplink ports. It provides Layer 2 switching features, a total PoE budget of 370W and support for IEEE 802.3af/at standards, enabling power delivery to PoE devices such as VoIP phones, wireless access points and network cameras. The switch includes IPv6 management, security and multicast control for networks migrating to or operating with IPv6.

Advantages

The GEP-2652 delivers per-port PoE output up to 30W, flexible power allocation across 24 PoE ports and dual Gigabit SFP ports for fiber uplinks. Its web-smart management simplifies configuration and monitoring while IPv6 support expands compatibility with modern network requirements. The 370W PoE budget helps power multiple devices without external injectors.

Key specifications

  • Ports: 24 x PoE (10/100/1000) and 2 x Gigabit SFP
  • PoE standard: IEEE 802.3af/at
  • Total PoE budget: 370W
  • Max PoE per port: 30W
  • Switch type: Web-smart, Layer 2 features
  • IPv6: management, security and multicast control

How to use

Install the switch in a standard 19-inch rack or on a stable surface and connect uplink fiber modules to the SFP ports if required. Connect PoE-powered devices to the PoE ports; the switch will negotiate power automatically according to IEEE 802.3af/at. Configure VLANs, QoS and IPv6 settings through the web management interface to integrate the switch into your existing network and apply security and multicast policies as needed.

Recommendations

For reliable operation, ensure the total connected PoE load does not exceed the 370W budget and verify cable and device compatibility with IEEE 802.3af/at. Use appropriate SFP transceivers for the required fiber type and test IPv6 settings in a controlled environment before wide deployment.
Key Highlights
  • 24 Gigabit PoE ports and 2 Gigabit SFP slots
  • IEEE 802.3af/at PoE compliant to simplify deployment and installation
  • Total PoE power budget: 370W, up to 30W per port
  • Supports port-based VLAN, IEEE 802.1Q VLAN Tagging and GVRP
  • IEEE 802.1d/w/s Spanning Tree Protocol (STP) and port mirroring
  • Supports IPv4/IPv6 network operation
  • Supports unknown unicast / broadcast / multicast storm control
  • MLD, Telnet, SNMP V1, V2c & V3, RMON, Web Browser, and TFTP Management
  • IP Multicast Filtering through IGMP Snooping V1 / V2 / V3
  • Dynamic ARP Inspection (DAI) protects switches against ARP spoofing
  • Managed L2
  • Quality of Service (QoS) support
  • Basic switching RJ-45 Ethernet ports quantity: 24 Console port: RJ-45
  • MAC address table: 8000 entries
  • Access Control List (ACL)
  • Rack mounting
  • Power over Ethernet (PoE)
Specifications
10G support
No
AC input frequency
50 - 60 Hz
AC input voltage
100 - 240 V
Access Control List (ACL)
Yes
ARP inspection
Yes
Authentication
Guest VLAN, Web-based authentication
Authentication type
RADIUS
Basic switching RJ-45 Ethernet ports quantity
24
Basic switching RJ-45 Ethernet ports type
Gigabit Ethernet (10/100/1000)
Broadcast storm control
Yes
Cables included
AC
Certification
CE
Compliance certificates
RoHS
Console port
RJ-45
Country of origin
China
Depth
208 mm
DHCP features
DHCP snooping
DoS attack prevention
Yes
Firmware upgradeable
Yes
Forwarding rate
38.69 Mpps
GARP VLAN Registration Protocol (GVRP)
Yes
Gigabit Ethernet (copper) ports quantity
24
Harmonized System (HS) code
85176990
Height
44 mm
Housing material
Metal
IGMP proxy
Yes
IGMP snooping
Yes
Input current
6.5 A
Installed SFP modules quantity
0
Installed SFP+ modules quantity
0
Internal memory
8 MB
IPv4 & IPv6 features
IPv6 Telnet
Jumbo frames
9000
Jumbo frames support
Yes
LED indicators
Link, PoE, Power
Link aggregation
Yes
MAC address table
8000 entries
Multicast Listener Discovery (MLD) snooping
v1/v2
Multicast support
Yes
Network virtualization technologies
Q-in-Q tunneling
Networking standards
IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ag, IEEE 802.1p, IEEE 802.1s, IEEE 802.1v, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ad, IEEE 802.3ah, IEEE 802.3az, IEEE 802.3x, IEEE 802.3z
Number of VLANs
4000
Operating relative humidity (H-H)
10 - 90%
Operating temperature (T-T)
0 - 45 °C
Package depth
295 mm
Package height
88 mm
Package type
Box
Package weight
4.2 kg
Package width
555 mm
Packet buffer memory
128 MB
Password protection
Yes
Port mirroring
Yes
Power connector
AC-in jack
Power consumption (max)
435 W
Power over Ethernet (PoE)
Yes
Power over Ethernet (PoE) ports quantity
24
Power over Ethernet (PoE) power per port
30 W
Product colour
Grey
QinQ implementation
Selective QinQ
Quality of Service (QoS) support
Yes
Queue scheduling algorithms
Priority queuing (PQ), Weighted Round Robin (WRR)
Quick start guide
Yes
Rack mount kit
Yes
Rack mounting
Yes
Rate limiting
Yes
Reset button
Yes
Resource CD
Yes
Rubber feet
Yes
Security algorithms
SNMPv3
SFP module slots quantity
2
Spanning tree protocol
Yes
SSH/SSL support
Yes
Storage relative humidity (H-H)
5 - 90%
Storage temperature (T-T)
-40 - 70 °C
Store-and-forward
Yes
Switch layer
L2
Switch type
Managed
Telnet
Yes
Total Power over Ethernet (PoE) budget
370 W
Virtual LAN features
MAC address-based VLAN, Port-based VLAN, Protocol-based VLAN, Tagged VLAN, VLAN Identifier ( VLAN ID), Voice VLAN
VLAN support
Yes
Weight
3.87 kg
Width
440 mm
