R982
LevelOne's SFP-Plus Transceivers are hot-swappable multi-purpose optical modules support 10Gigabit Ethernet applications across most switching and routing platforms. The transceivers support to operate at 10Gbps serial optical data transfer rates on a single duplex fiber core with a length of up to ... Read More
Stock 48 Code 2555484 Brand LEVELONE Model SFP-6101 Warranty 2 Years

Shipping & Returns

Estimated delivery Tuesday, September 29
You will be kept updated through our detailed tracking system
Payment options
EFTPayFastBank CardSnapScanZapperGoogle PayApple PayMobicredMoreTymePay on Arrival
LevelOne's SFP-Plus Transceivers are hot-swappable multi-purpose optical modules support 10Gigabit Ethernet applications across most switching and routing platforms. The transceivers support to operate at 10Gbps serial optical data transfer rates on a single duplex fiber core with a length of up to 40km (SMF) or 300m (MMF), ideally suited for data centers, enterprise and storage area networks. In addition, the LevelOne SFP-Plus transceivers adopt the most advanced technology to minimize the power consumption in ultra-high speed.

- High-quality 10Gbase short range SFP-Plus transceiver
- Comply with SFP Multi-Sourcing Agreement (MSA) to work in MSA compliant devices
- Supports Digital Optical Monitoring (DOM) and Digital Diagnostics Monitoring Interface (DDMI) for easy status monitoring
- Hot-swappable providing non-stop service
- Provides duplex LC connector
- Operating temperature: 0°C ~ 70°C
Key Highlights
  • SFP+ Fiber optic 10000 Mbit/s
  • Wavelength: 850 nm
  • Hot-swap
  • Input voltage: 3.3 V
Specifications
Certification
CE, FCC
Compliance certificates
RoHS
Depth
12 mm
Duplex system
Full
Fiber optic connector
LC
Fiber ports quantity
1
Harmonized System (HS) code
85369010
Height
13.7 mm
Hot-swap
Yes
Input voltage
3.3 V
Interface type
SFP+
Maximum current
0.18 A
Maximum data transfer rate
10000 Mbit/s
Maximum transfer distance
300 m
Maximum voltage
3.6 V
Multi-mode fiber (MMF) supported
Yes
Networking standards
IEEE 802.3ae
Operating relative humidity (H-H)
5 - 95%
Operating temperature (T-T)
0 - 70 °C
Package depth
20 mm
Package height
65 mm
Package weight
35 g
Package width
106 mm
Quantity per pack
1 pc(s)
Safety
EN 60825-1
SFP transceiver type
Fiber optic
Storage temperature (T-T)
-40 - 85 °C
Tx power (max)
-1 dBmW
Tx power (min)
-6.5 dBmW
Wavelength
850 nm
Weight
20 g
Width
57 mm

Leaflet

Open Leaflet
