Lenovo 7ZT7A00549 network card Internal Ethernet 10000 Mbit/s

Lenovo 7ZT7A00549 network card Internal Ethernet 10000 Mbit/s
Lenovo 7ZT7A00549 network card Internal Ethernet 10000 Mbit/s
R5,693
The Intel Ethernet Connection X722 is a network controller embedded into the Intel C624 "Lewisburg" PCH chipset of Lenovo ThinkSystem servers. The controller connects to available 10 GbE and 1 Gigabit Ethernet LAN-on-motherboard (LOM) adapter cards and onboard connectors to provide a comprehensive 1... Read More
Stock 1 Code 2412927 Brand LENOVO Model 7ZT7A00549 Warranty 2 Years

Shipping & Returns

Estimated delivery Thursday, October 1
You will be kept updated through our detailed tracking system
Payment options
EFTPayFastBank CardSnapScanZapperGoogle PayApple PayMobicredMoreTymePay on Arrival
The Intel Ethernet Connection X722 is a network controller embedded into the Intel C624 "Lewisburg" PCH chipset of Lenovo ThinkSystem servers. The controller connects to available 10 GbE and 1 Gigabit Ethernet LAN-on-motherboard (LOM) adapter cards and onboard connectors to provide a comprehensive 1 GbE / 10 GbE networking solution for ThinkSystem customers.

ThinkSystem servers support either 10 Gb Ethernet copper or optical connections, or Gigabit Ethernet connections depending on the server model.

The following figure shows the ThinkSystem 10Gb 4-port SFP+ LOM adapter which provides four SFP+ cages for optical or direct-attach copper (DAC) connectivity.

Lenovo 7ZT7A00549. Internal. Connectivity technology: Wired, Host interface: PCI Express, Interface: Ethernet. Maximum data transfer rate: 10000 Mbit/s. Product colour: Green

Key Highlights
  • Wired
  • PCI Express Ethernet
  • 10000 Mbit/s 10GBase-T
  • Internal Chipset: Intel® C624
Specifications
Cabling technology
10GBase-T
Certification
UL recognized to UL60950-1 2nd Edition FCC Rules, Part 15, Class A Australian EMC Framework (RCM) Japan VCCI, Class A Industry Canada, ICES-003, Class A EU (CE Mark) Korea KC-RRA, Class A
Chipset
Intel® C624
Compatible products
SR630 SR650 SR850 SR860 SR950
Compliance certificates
RoHS
Connectivity technology
Wired
Ethernet LAN
Yes
Ethernet LAN (RJ-45) ports
4
Ethernet LAN data rates
10,100,1000,10000 Mbit/s
Flow control support
Yes
Harmonized System (HS) code
85176990
Host interface
PCI Express
Interface
Ethernet
Internal
Yes
Jumbo frames
9728
Jumbo frames support
Yes
Linux operating systems supported
Red Hat Enterprise Linux WS 6.0, Red Hat Enterprise Linux WS 7.0, openSUSE 11.3, openSUSE 11.4, openSUSE 12.1, openSUSE 12.2
Maximum data transfer rate
10000 Mbit/s
Networking standards
IEEE 802.1Q, IEEE 802.1Qbg, IEEE 802.1p, IEEE 802.3ad, IEEE 802.3x
Number of VLANs
4096
Other operating systems supported
VMware vSphere ESXi
PCI-SIG* SR-IOV Capable
Yes
Product colour
Green
Quality of Service (QoS) support
Yes
Receive Side Scaling (RSS)
Yes
Security algorithms
SNMP
Server operating systems supported
Windows Server 2012 R2, Windows Server 2012 R2 x64, Windows Server 2016
VLAN tagging
Yes
