LED driver MEAN WELL XLG-100-24-A 100W IP20 100-305V 4A 24V

The MEAN WELL XLG-100-24-A is an AC-DC single-output LED driver providing 24 VDC at 4 A with a constant power mode and built-in power factor correction (PFC). Designed for indoor lighting applications, the unit delivers up to 100 W output and comes in a metal housing with an IP20 protection rating. The driver supports an AC input range of 100–305 VAC and includes a built-in potentiometer for adjustable output current.

Advantages

The XLG-100-24-A offers stable constant-power output with integrated PFC for improved electrical efficiency and reduced mains distortion. Its metal housing ensures mechanical robustness and thermal stability for indoor installations. The built-in potentiometer allows fine adjustment of the output current without external components, and the wide input voltage range supports international mains supplies.

Suitable for

• Indoor LED fixtures and panels
• Architectural and commercial lighting installations
• Retrofitting existing indoor lighting systems

Key specifications

• Model: MEAN WELL XLG-100-24-A
• Output: 24 V DC, 4 A
• Output power: 100 W (constant power mode)
• Input voltage: 100–305 VAC
• Protection class: IP20 (indoor use)
• Housing: metal
• Features: built-in PFC, built-in potentiometer

How to use

Install the LED driver indoors in a well-ventilated location and secure it according to local electrical codes. Connect the AC input (100–305 VAC) to the mains, observe correct polarity on the DC output, and wire the LED load rated for 24 VDC. Use the built-in potentiometer to adjust the output current to match the LED module specifications. Ensure all connections are made with the power disconnected and recheck wiring before powering on.

Recommendations

Use the XLG-100-24-A in dry indoor environments only (IP20). Allow sufficient clearance for heat dissipation, avoid mounting near direct heat sources, and verify that the connected LED load does not exceed the 100 W/4 A output rating. For compliance and safety, follow local installation standards and the manufacturer's datasheet.
