MEAN WELL A301-100-F3 DC/DC Constant Current LED Driver 100W 3.5A 3-30V

The MEAN WELL A301-100-F3 is a DC/DC constant current LED driver delivering up to 100 W of power with a high efficiency of 96%. It operates from a 9-36 V DC input and provides a constant current of 3500 mA across an output voltage range of 3-30 V DC. This driver supports 3-in-1 dimming (0-10 VDC, PWM, resistance) and features comprehensive protections including short circuit, over voltage, over temperature, and input under voltage. Its wide operating temperature range from -40°C to +70°C and free air convection cooling make it suitable for demanding LED lighting applications.

Advantages

High efficiency up to 96% reduces energy loss and heat generation. The 3-in-1 dimming capability allows flexible control of LED brightness. Robust protections ensure reliable operation and long service life. The wide input voltage range (9-36 V DC) accommodates various DC power sources, including batteries and renewable energy systems. Compact design with free air convection cooling simplifies installation and eliminates the need for additional cooling components.

Suitable for

• LED lighting systems in industrial and commercial environments
• Automotive and marine LED lighting powered by DC batteries
• Solar-powered LED lighting and off-grid applications
• Architectural and accent lighting requiring dimming control
• Any DC-powered LED application needing a reliable constant current source

Key specifications

• Output power: 100 W
• Input voltage: 9-36 V DC
• Output current: 3500 mA (constant current)
• Output voltage: 3-30 V DC
• Efficiency: 96%
• Dimming: 3-in-1 (0-10 VDC, PWM, resistance)
• Protections: short circuit, over voltage, over temperature, input under voltage
• Operating temperature: -40°C to +70°C
• Cooling: free air convection
• Isolation voltage: 1.5 kV AC
• MTBF: >1,000,000 hours
• Compliance: EN55015, EN61347-1, EN61347-2-13
• Warranty: 3 years

Recommendations

For optimal performance, ensure the input voltage stays within the specified range and provide adequate ventilation. When using dimming, verify compatibility with the control signal type. This driver is ideal for integrating into LED luminaires where high efficiency and reliability are paramount.
