Name: Hikvision DS-2CD2543G2-IS(2.8MM) 4 MP AcuSense Dome IP Security Camera – 2.8 mm
Brand: Hikvision
SKU: 1162593
Price: 4637.00 ZAR
Availability: InStock

Hikvision DS-2CD2543G2-IS(2.8MM) 4 MP AcuSense Dome IP Security Camera – 2.8 mm

R4,637

+R15 store credit

PDF

Qty

Add to Cart

Add to Wish List Compare this Product

PDF

Stock 14 Code 1162593 Model DS-2CD2543G2-IS(2.8MM) Warranty 2 Years

DepartmentSmart Home & Security

CategorySecurity Cameras

BrandHikvision

Shipping & Returns

Estimated delivery Thursday, November 19

You will be kept updated through our detailed tracking system

Payment options

EFTPayFastBank CardSnapScanZapperGoogle PayApple PayMobicredMoreTymePay on Arrival

Ask a question – the AI assistant answers instantly.

html .tab-container.product_extra.product_tabs.product_tabs-default:not(.dn-product-info-ready)>*{opacity:1!important;visibility:visible!important;pointer-events:auto!important}html .tab-container.product_extra.product_tabs.product_tabs-default:not(.dn-product-info-ready)::before,html .tab-container.product_extra.product_tabs.product_tabs-default:not(.dn-product-info-ready)::after{display:none!important}html .tab-container.product_extra.product_tabs.product_tabs-default:not(.dn-product-info-ready){min-height:0!important}

Description

The Hikvision DS-2CD2543G2-IS(2.8MM) Dome is an outdoor IP security camera with a 2688 x 1520 resolution and a CMOS sensor, engineered for wired installations on ceilings or walls. It provides a 360° rotation capability, a 104.3° horizontal viewing angle and a 55.9° vertical viewing angle, with detection range up to 64 m. The camera is white, weighs 0.38 kg and supports video motion detection for continuous surveillance in varied outdoor environments.

Advantages

Equipped with Hikvision AcuSense deep-learning algorithms, this camera classifies human and vehicle targets to reduce false alarms and improve alarm relevance. The high-resolution sensor delivers clear image detail at 2688 x 1520 pixels while a 30 fps frame rate ensures smooth motion capture. Designed for wired connectivity and outdoor placement, the dome form factor supports both ceiling and wall mounting for flexible installation.

Suitable for

Perimeter monitoring of residential or commercial properties
Parking lots and vehicle access control
Building entrances and public walkways
Outdoor surveillance for small to medium-sized sites

Key specifications

Model: DS-2CD2543G2-IS(2.8MM)
Resolution: 2688 x 1520 (approx. 4 MP)
Frame rate: 30 fps
Lens: 2.8 mm
Rotation: 360°
Horizontal viewing angle: 104.3°; Vertical viewing angle: 55.9°
Detection distance: up to 64 m
Sensor: CMOS
Connectivity: Wired Ethernet (no Wi‑Fi)
Placement: Outdoor; Mounting: Ceiling or Wall
Features: Video motion detection, AcuSense human/vehicle classification
Colour: White; Weight: 0.38 kg

How to use

Mount the Hikvision DS-2CD2543G2-IS on a suitable ceiling or wall using the recommended fixtures and ensure a stable wired Ethernet connection. Configure network settings and enable AcuSense classification in the camera’s web interface or management software to receive human and vehicle alarms. Adjust the camera rotation and viewing angle to cover desired areas and set motion detection zones and sensitivity according to the monitored environment.

Recommendations

For optimal performance, install the camera at a height and angle that provide unobstructed views of entrances and lanes; use PoE-capable switches or dedicated power and surge protection for outdoor reliability. Regularly update firmware and verify AcuSense settings to maintain accurate human and vehicle classification.

Key Highlights

Perimeter monitoring of residential or commercial properties
Parking lots and vehicle access control
Building entrances and public walkways
Outdoor surveillance for small to medium-sized sites
Model: DS-2CD2543G2-IS(2.8MM)
Resolution: 2688 x 1520 (approx. 4 MP)
Frame rate: 30 fps
Lens: 2.8 mm
Rotation: 360°
Horizontal viewing angle: 104.3°; Vertical viewing angle: 55.9°
Detection distance: up to 64 m
Sensor: CMOS
Connectivity: Wired Ethernet (no Wi‑Fi)
Placement: Outdoor; Mounting: Ceiling or Wall
Features: Video motion detection, AcuSense human/vehicle classification
Colour: White; Weight: 0.38 kg

Specifications

Active tampering alarm

Yes

Alarm input channels

Alarm input/output

Yes

Alarm output channels

Angle of rotation

360 °

Anti-flicker

Yes

Audio formats supported

AAC, MP3

Audio input channels

Audio output channels

Audit log

Yes

Automatic Network Replenishment (ANR)

Yes

Back Light Compensation (BLC)

Yes

Behavior analysis

Intrusion detection, Line crossing detection

Bit rate

32 Kbps - 8 Mbps

Bit rate control

Constant Bit Rate (CBR)/Variable Bit Rate (VBR)

Bit rate range

8 - 320

Bluetooth

Brand

Hikvision

Built-in HDD

Built-in microphone

Yes

Camera pan control

Yes

Camera shutter speed

1/3 - 1/100000

Camera tilt control

Yes

Card reader integrated

Yes

Certification

WEEE, Reach, CE-RoHS

Client interoperability

iVMS-4200, Hik-Connect, Hik-Central

Compatible memory cards

MicroSD (TransFlash)

Connectivity technology

Wired

Day/night mode

Yes

DC output current

0.45 A

DC output voltage

Detect distance

64 m

Diameter

110 mm

Dynamic range

120 dB

Ethernet interface type

Fast Ethernet

Ethernet LAN

Yes

Ethernet LAN (RJ-45) ports

Fixed focal length

2.8 mm

Form factor

Dome

Frame rate

30 fps

Gain control type

Auto

Heartbeat

Yes

Height

57.4 mm

Highlight Compensation (HLC)

Yes

HTTPS encryption

Yes

I/O ports

line in, line out

Identify distance

6 m

IK code

IK08

Image quality adjustment

Brightness, Contrast, Saturation, Sharpness

Infra-red wavelength

850 nm

Infrared (IR) cut-off filter

Yes

Intelligent Video Surveillance (IVS) system features

Face detection

International Protection (IP) code

IP67

IP address filtering

Yes

Iris

Yes

Languages support

Multi

LED type

Lens mount interface

M12

Lens viewing angle, diagonal

123.8

Lens viewing angle, horizontal

104.3

Lens viewing angle, vertical

55.9

Live view

Yes

Maximum aperture number

1.6

Maximum memory card size

256 GB

Maximum resolution

2688 x 1520

Minimum illumination

0 lx

Model

DS-2CD2543G2-IS(2.8MM)

Mounting type

Ceiling/Wall

Night vision

Yes

Night vision distance

Noise reduction

Yes

Noise reduction technology

3D noise reduction

Number of cameras

Number of languages

Number of lenses

Number of sensors

Number of simultaneous live view channels

6 channels

Number of users

32 user(s)

Observe distance

25 m

Operating relative humidity (H-H)

0 - 95

Operating temperature (T-T)

-30 - 60

Optical sensor size

25.4 / 3

Package depth

134 mm

Package height

108 mm

Package weight

615 g

Package width

134 mm

Pan range

-30 - 30

Password protection

Yes

Password reset via email

Yes

Pixel counter

Yes

Placement supported

Outdoor

Power consumption (max)

5.5 W

Power consumption (Power over Ethernet (PoE))

7 W

Power source type

DC, PoE

Product colour

White

Progressive scan

Yes

Quality of Service (QoS) support

Yes

Recognize distance

13 m

Region of Interest (ROI) encoding

Yes

Reset button

Yes

Sample rates

8 - 48

Sensor type

CMOS

Signal-to-Noise Ratio (SNR)

52 dB

Storage relative humidity (H-H)

0 - 95

Storage temperature (T-T)

-30 - 60

Supported graphics resolutions

640 x 360, 640 x 480 (VGA), 1280 x 720 (HD 720), 1920 x 1080 (HD 1080), 2688 x 1520

Supported network protocols

TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, NTP, UPnP, SMTP, IGMP, 802.1X (except for -W model), QoS, IPv6, UDP, Bonjour, SSL/TLS, PPPoE, WebSocket, WebSockets

Tilt angle range

0 - 75

Total megapixels

4 MP

Type

IP security camera

User access level

Administrator, Operator, User

Video compression formats

H.264, H.264+, H.265, H.265+, M-JPEG

Video motion detection

Yes
