HPE X2A0 25GBase Direct Attach Cable - SFP28 to SFP28 - 5m Active Optical Cable

The HPE X2A0 25GBase Direct Attach Cable is a high-performance active optical cable designed for reliable 25 Gbps connectivity in data center environments. With SFP28 connectors on both ends and a length of 5 meters, this cable provides a cost-effective and energy-efficient solution for server-to-switch and switch-to-switch interconnections.

Advantages

This active optical cable offers low power consumption (<1W per end), hot-swappable convenience, and compliance with IEEE 802.3by and SFF-8402 standards. Its LSZH jacket ensures safety in confined spaces, while the multimode fiber supports high-bandwidth applications.

Suitable for

• Data center interconnects
• Server-to-switch connections
• Switch-to-switch links
• HPE FlexFabric 5940, 5950, 5700 series and other SFP28-enabled devices

Key specifications

• Cable Type: Active Optical Cable (AOC)
• Connector Type: SFP28 to SFP28
• Data Transfer Rate: 25 Gbps
• Cable Length: 5 m (16.4 ft)
• Fiber Type: Multimode Fiber (MMF)
• Active/Passive: Active
• Hot-Swappable: Yes
• Power Consumption: <1W per end (typical)
• Operating Temperature: 0°C to 70°C
• Storage Temperature: -40°C to 85°C
• Humidity Range: 0% to 85% (non-condensing)
• Standards Compliance: IEEE 802.3by (25GBASE-SR), SFF-8402 (SFP28 MSA)
• Jacket Material: LSZH (Low Smoke Zero Halogen)

Recommendations

For optimal performance, pair this cable with HPE SFP28-compatible switches and servers. Ensure proper handling and storage within specified environmental ranges.
