Hikvision Pro Series DS-2CD2167G2H-LISU Bullet IP Camera 3200×1800, ColorVu, 2.8mm, Outdoor, Ceiling/Wall

Hikvision Pro Series DS-2CD2167G2H-LISU is an outdoor bullet IP camera with 3200×1800 (6 MP) resolution and ColorVu low-light technology. The camera uses a 1/1.8" CMOS sensor and a fixed 2.8 mm lens with a 105.1° horizontal field of view, delivering color or black-and-white images at up to 30 fps. Designed for ceiling or wall mounting, the unit supports wired Ethernet connectivity, robust outdoor protection, and integrated audio capture for enhanced situational awareness. Detection, observation and recognition ranges support perimeter and property surveillance scenarios.

Advantages

The camera provides high-resolution, detailed imaging in both daytime and low-light conditions thanks to ColorVu and Smart Hybrid Light technologies. Wide dynamic range (130 dB WDR) preserves image clarity in scenes with strong backlight. Efficient H.265+ compression reduces storage and bandwidth requirements while maintaining image quality. Built-in analytics for human and vehicle classification based on deep learning improves detection accuracy, and the integrated microphone adds audio context to video recordings. Durable IP67 and IK10 ratings make the housing suitable for harsh outdoor environments.

Suitable for

• Perimeter and property surveillance for residential and commercial sites
• Parking lots and driveways where long detection range and color night monitoring are needed
• Building entrances, façades and loading bays requiring ceiling or wall mounting

Key specifications

• Image sensor: 1/1.8" CMOS, 6 MP (3200 × 1800)
• Lens: 2.8 mm fixed, ~105.1° horizontal field of view
• Frame rate: up to 30 fps
• Low-light: ColorVu with Smart Hybrid Light for color imaging in low illumination
• Wide dynamic range: 130 dB WDR
• Compression: H.265+ support for efficient storage
• Analytics: Deep-learning based human and vehicle classification
• Audio: Built-in microphone for real-time audio capture
• Mounting: Ceiling or wall mount supported
• Ingress and impact protection: Outdoor-rated housing with dust/water resistance and vandal resistance
• Connectivity: Wired Ethernet LAN
• Physical: Weight approx. 0.525 kg; product color: white

How to use

Install the camera on a stable ceiling or wall surface using the supplied mounting hardware, positioning the 2.8 mm lens to cover the intended field of view. Connect the camera to a PoE-capable switch or injector for power and network access, or follow the wiring requirements for your networked video recorder. Configure basic settings via the Hikvision web interface or client software: set resolution and frame rate (up to 30 fps), enable H.265+ compression, adjust exposure and Smart Hybrid Light modes for optimal low-light color performance, and enable analytics such as human/vehicle classification. Verify audio capture if required and secure network access with appropriate credentials.

Recommendations

For best results, mount the camera at a height and angle that balance wide coverage with the required recognition distance: observation up to approximately 35 m and recognition up to approximately 17 m. Use PoE for simplified installation and reliable power over the Ethernet connection, and regularly update firmware and review analytics thresholds to reduce false alarms in busy scenes.
