Hikvision DS-9664NI-M8 64-Channel 4K NVR Network Video Recorder

The Hikvision DS-9664NI-M8 is a high-performance 64-channel network video recorder (NVR) designed for large-scale surveillance systems. With support for up to 64 IP cameras and 400 Mbps incoming bandwidth, this 2U rackmount NVR delivers reliable 4K recording and playback. It features 8 SATA HDD bays (up to 10 TB each), RAID support, and dual Gigabit Ethernet ports for seamless network integration.

Advantages

This NVR offers exceptional scalability and data protection with RAID0/1/5/6/10 configurations. Its powerful decoding capability allows simultaneous playback of up to 16 channels at 1080p. The dual HDMI outputs support 4K resolution, making it ideal for control room monitoring.

Suitable for

• Large retail stores and shopping malls
• Corporate office buildings and campuses
• Warehouses and logistics centers
• Government and public facilities
• Educational institutions

Key specifications

• 64-channel IP video input
• 400 Mbps incoming/outgoing bandwidth
• 8 SATA HDD bays, up to 10 TB each
• RAID0/1/5/6/10 support
• 2x HDMI (4K), 2x VGA (1080p) outputs
• Decoding: 2-ch@12 MP, 4-ch@8 MP, 8-ch@4 MP, 16-ch@1080p
• H.265+/H.265/H.264+/H.264/MPEG4 compression
• 2x Gigabit Ethernet ports
• 16 alarm inputs, 8 alarm outputs
• 2U rackmount chassis

Recommendations

For optimal performance, use Hikvision H.265+ cameras and enterprise-grade SATA HDDs. Ensure proper ventilation in the rack cabinet. The NVR supports up to 10 TB per HDD; for RAID5 configurations, use drives of identical capacity.
