Hikvision DS-3WF500T-EI-2N/P 5 GHz Outdoor Wireless Bridge 300 Mbps 12 dBi

The Hikvision DS-3WF500T-EI-2N/P is a high-performance outdoor wireless bridge designed for long-range point-to-point and point-to-multipoint connections. Operating in the 5 GHz band with 2x2 MIMO technology, it delivers up to 300 Mbps wireless speed and a transmission distance of up to 5 km. Built with an IP65 weatherproof enclosure, it is ideal for surveillance backhaul, industrial networking, and campus connectivity.

Advantages

Reliable 5 GHz wireless link with 12 dBi directional antenna for extended range. Supports multiple operating modes including AP, Station, Repeater, WISP, and Router. Passive PoE (24V) simplifies installation with power and data over a single cable. Robust ESD and lightning protection ensure durability in outdoor environments.

Suitable for

• Surveillance system backhaul
• Industrial network extension
• Campus and enterprise connectivity
• WISP deployments

Key specifications

• Wireless Standard: IEEE 802.11a/n/ac
• Frequency Band: 5 GHz
• Max Wireless Speed: 300 Mbps
• Antenna: Built-in Directional, 12 dBi gain
• MIMO: 2x2
• Ethernet Ports: 2x 10/100 Mbps (LAN1 PoE IN, LAN2 PoE OUT)
• PoE: 24V Passive PoE
• Power Consumption: < 6 W
• Operating Modes: AP, Station, Repeater, WISP, Router
• Enclosure Rating: IP65
• Operating Temperature: -30°C to 65°C
• Wireless Security: WPA/WPA2, WPA-PSK/WPA2-PSK (AES/TKIP)
• Max Distance: Up to 5 km (Line of Sight)
• Management: Web-based UI
• ESD Protection: 15KV
• Lightning Protection: 6KV
• Mounting: Pole Mount, Wall Mount

Recommendations

For optimal performance, ensure clear line of sight between units. Use with Hikvision PoE switches or injectors for seamless integration. Ideal for connecting remote IP cameras or extending network coverage across large areas.
