Hikvision DS-2CD1F47G3H-LIUF/SX 4MP Fixed Dome Network Camera with Built-in Microphone, 2.8mm Lens, IP67, IK10, PoE

Ensuring reliable surveillance in demanding environments often means choosing between ruggedness and image clarity. The Hikvision DS-2CD1F47G3H-LIUF/SX 4MP fixed dome network camera eliminates that compromise, delivering crisp 2560 × 1440 video in a compact housing that withstands vandalism and harsh weather. Its built-in microphone captures audio evidence, while PoE support simplifies installation with a single cable for power and data.

Who is it for

This camera suits small businesses, retail stores, offices, and residential users who need a discreet yet durable surveillance solution. It is ideal for monitoring entrances, corridors, and other indoor or outdoor areas where space is limited but image quality cannot be sacrificed. Installers will appreciate the straightforward setup and flexible power options.

Main features

• 4-megapixel progressive scan CMOS sensor for high-resolution 2560 × 1440 video.
• Fixed 2.8mm lens with 98° horizontal field of view for wide coverage.
• IR night vision up to 30 metres for clear images in complete darkness.
• Built-in microphone for audio recording without extra equipment.
• IP67 weatherproof and IK10 vandal-resistant housing for outdoor or high-risk areas.
• H.265+ compression to save bandwidth and storage while maintaining quality.
• Micro SD card slot supporting up to 256 GB for local recording.
• Power over Ethernet (802.3af) or 12 VDC power options for flexible installation.

Specifications

• Image sensor: 1/3" progressive scan CMOS
• Max resolution: 2560 × 1440 (4 MP)
• Lens: fixed focal, 2.8 mm
• Field of view: 98° horizontal
• IR range: up to 30 m
• Video compression: H.265+/H.265/H.264+/H.264
• Audio: built-in microphone
• Storage: Micro SD/SDHC/SDXC slot, up to 256 GB
• Network interface: 1× RJ45 10M/100M Ethernet
• Power supply: 12 VDC, PoE (802.3af)
• Power consumption: max 6.5 W
• Operating temperature: -30 °C to 60 °C
• Ingress protection: IP67
• Vandal resistance: IK10

Tips

For optimal coverage, mount the camera at a height of 2.5–3 metres and angle it slightly downward. Use a PoE switch or injector to reduce cabling complexity. To maximise storage efficiency, enable H.265+ and motion-triggered recording. Regularly check the lens for dust or debris, especially in outdoor installations.
