Hand Tool Shaft Gedore 8697240

Hand Tool Shaft Gedore 8697240 is a replacement shaft for hand tools with an oval fixing hole, manufactured according to DIN 5111. It is available in ash (E 4 E) or hickory (E 4 H) handle types and is intended for use with engineers' hammers and similar striking tools. The shaft is compact and lightweight, matching common hand tool dimensions for easy handling and storage.

Advantages

The Gedore 8697240 shaft provides a DIN 5111-compliant fit and an oval fixing hole for secure attachment to hammer heads. Offered in ash or hickory, it combines resilience with shock absorption appropriate for striking applications. Its compact dimensions and light weight support precise control and comfortable handling during use.

Suitable for

Key specifications

How to use

Select the appropriate handle material (ash or hickory) and insert the shaft into the hammer head so the oval fixing hole aligns with the head's wedge slot. Secure the head with the appropriate wedge or fixing method specified for the hammer. Check the fit to ensure the head is tight and correctly seated before use. Inspect the shaft and head connection regularly for wear or loosening.

Recommendations

Use the Gedore 8697240 shaft only with compatible hammer heads designed for an oval fixing hole and follow DIN 5111 guidance for installation. Replace the shaft if you observe cracks, excessive wear, or any loosening to maintain safe operation.
