Hager CDC225J Neutral Bar 25 Way 125A 400V Grey/Blue

The Hager CDC225J is a high-quality neutral bar designed for use in Hager consumer units and distribution boards. It provides a reliable and organized connection point for neutral conductors, ensuring safe and efficient electrical distribution. With 25 ways and a rated current of 125A, it is suitable for a wide range of residential and commercial applications.

Advantages

This neutral bar offers easy installation and secure screw terminals for up to 25 branch circuits. Its compact design saves space within the enclosure, while the insulated polyamide housing ensures safety and durability. The grey and blue color coding aids in identification.

Suitable for

• Hager consumer units and distribution boards
• Residential and commercial electrical installations
• Neutral conductor termination in multi-circuit systems

Key specifications

• Number of Ways: 25
• Rated Current: 125 A
• Rated Voltage: 400 V AC
• Main Conductor Capacity: Up to 25 mm²
• Branch Conductor Capacity: Up to 16 mm²
• Conductor Material: Copper
• Insulation Material: Polyamide (PA)
• Mounting Type: Screw-fixed
• Colour: Grey / Blue
• Standard: EN 60947-7-1

Recommendations

For optimal performance, use with Hager enclosures and ensure proper torque settings for screw terminals. Always follow local electrical codes and regulations.
