Grenton OCCY Presence Sensor PIR 868 MHz White

The Grenton OCCY Sensor is a compact PIR presence detector designed for indoor use within the Grenton Smart Home ecosystem. It reliably detects movement up to 8 meters with a 120° angle and integrates ambient light and temperature sensors for enhanced automation scenarios.

Advantages

Wireless installation via adhesive or screws, battery-powered with up to 2 years of life, and seamless communication over the Grenton Mesh Network at 868 MHz. The built-in tamper protection and LED indicator provide added security and user feedback.

Suitable for

• Smart home presence detection in rooms, corridors, and offices
• Triggering lighting, HVAC, or security routines based on occupancy
• Integration with Grenton GATE for advanced automation

Key specifications

• Detection Technology: PIR (Passive Infrared)
• Wireless Protocol: Grenton Mesh Network
• Frequency: 868 MHz
• Power Supply: 1x CR2032 Battery (included)
• Battery Life: Up to 2 years
• Detection Range: Up to 8 m
• Detection Angle: 120°
• Integrated Sensors: Ambient Light (Lux), Temperature
• Operating Temperature: 0°C to +50°C
• Mounting Type: Surface (Adhesive/Screws)
• Colour: White
• Material: Plastic
• Compatibility: Grenton GATE
• Tamper Protection: Yes
• LED Indicator: Yes

Recommendations

For optimal performance, mount the sensor at a height of 2–2.5 m, avoiding direct sunlight and heat sources. Pair with Grenton GATE for full smart home integration.
