Motherboard GIGABYTE H610M H V2, Intel H610, LGA 1700, Micro ATX

Motherboard GIGABYTE H610M H V2, Intel H610, LGA 1700, Micro ATX
Motherboard GIGABYTE H610M H V2, Intel H610, LGA 1700, Micro ATX
Motherboard GIGABYTE H610M H V2, Intel H610, LGA 1700, Micro ATX
Motherboard GIGABYTE H610M H V2, Intel H610, LGA 1700, Micro ATX
Motherboard GIGABYTE H610M H V2, Intel H610, LGA 1700, Micro ATX
36 mo.
Motherboard GIGABYTE H610M H V2, Intel H610, LGA 1700, Micro ATX
Motherboard GIGABYTE H610M H V2, Intel H610, LGA 1700, Micro ATX
Motherboard GIGABYTE H610M H V2, Intel H610, LGA 1700, Micro ATX
Motherboard GIGABYTE H610M H V2, Intel H610, LGA 1700, Micro ATX
Motherboard GIGABYTE H610M H V2, Intel H610, LGA 1700, Micro ATX
R1,550
The GIGABYTE H610M H V2 is a Micro ATX motherboard based on the Intel H610 chipset and equipped with an LGA 1700 socket to support Intel 14th generation Core processors. Designed for compact desktop builds, it provides a 4+1+1 hybrid digital VRM, two DDR5 memory slots supporting up to 96 GB (up to 5... Read More
Stock 100 Code 109016 Brand GIGABYTE Model H610M H V2 Warranty 3 Years

Shipping & Returns

Estimated delivery Thursday, October 1
You will be kept updated through our detailed tracking system
Payment options
EFTPayFastBank CardSnapScanZapperGoogle PayApple PayMobicredMoreTymePay on Arrival

The GIGABYTE H610M H V2 is a Micro ATX motherboard based on the Intel H610 chipset and equipped with an LGA 1700 socket to support Intel 14th generation Core processors. Designed for compact desktop builds, it provides a 4+1+1 hybrid digital VRM, two DDR5 memory slots supporting up to 96 GB (up to 5600 MHz), one PCIe 3.0 M.2 slot and standard connectivity including GbE LAN and USB 3.2 Gen 1. The board supports both HDD and SSD storage options and is suitable for building an efficient mainstream PC.

Advantages

The H610M H V2 combines a modern LGA 1700 socket and Intel H610 chipset for compatibility with current Intel CPUs while maintaining a compact Micro ATX form factor. DDR5 memory support and a 4+1+1 hybrid digital VRM help provide stable system performance for everyday computing, gaming or content creation. Onboard M.2 and USB 3.2 Gen 1 connectivity deliver flexible storage and peripheral options.

Suitable for

  • Compact desktop builds and home PCs
  • Mainstream gaming systems with single GPU configurations
  • Office and productivity workstations
  • Content creators needing a cost-effective platform with DDR5 support

Key specifications

  • Form factor: Micro ATX
  • Chipset: Intel H610 Express
  • Socket: LGA 1700 (supports Intel 14th gen Core CPUs)
  • Memory: 2 × DDR5 slots, up to 96 GB, up to 5600 MHz
  • Expansion: 1 × PCIe 3.0 M.2 slot
  • Connectivity: GbE LAN, USB 3.2 Gen 1

How to use

Install an LGA 1700-compatible Intel 14th generation CPU following standard anti-static precautions and secure it in the socket. Populate up to two DDR5 modules according to the motherboard manual to achieve desired capacity and dual-channel operation. Fit an M.2 SSD into the PCIe 3.0 M.2 slot or connect SATA drives as needed. Connect power, front-panel headers and peripherals, then configure BIOS/UEFI settings for memory frequency and boot order before installing the operating system.

Recommendations

For stable operation, use a quality power supply and adequate case airflow. When installing memory, consult the motherboard QVL or the manual for compatible DDR5 modules and populate slots in the recommended order to enable dual-channel performance.
Key Highlights
  • Supports Intel® Core™ 14th/ 13th /12th processors
  • Dual Channel Non-ECC Unbuffered DDR5, 2 DIMMs
  • 4+1+1 Hybrid Digital VRM Design
  • GbE LAN with Bandwidth Management
  • NVMe PCIe 3.0 x4 M.2
  • High Quality Audio Capacitors and Audio Noise Guard
  • Smart Fan 6 Features Multiple Temperature Sensors , Hybrid Fan Headers with FAN STOP
  • GIGABYTE APP Center, Simple and Easy Use
  • Anti-Sulfur Resistors Design
  • Intel LGA 1700 Intel® Celeron®, Intel® Core™ i3, Intel® Core™ i5, Intel® Core™ i7, Intel® Core™ i9, Intel® Pentium® Gold
  • PC micro ATX Intel H610 Express Realtek ALC897 7.1 channels
  • DDR5-SDRAM 2 DIMM Maximum internal memory: 96 GB
  • HDD & SSD M.2, SATA III Number of storage drives supported: 5
  • Intel HD Graphics
  • BIOS type: UEFI AMI 128 Mbit ACPI version: 5.0 Clear CMOS jumper Clear CMOS button
  • Gigabit Ethernet
Specifications
12V power connector
Yes
ACPI version
5.0
ATX Power connector (24-pin)
Yes
Audio chip
Realtek ALC897
Audio output channels
7.1 channels
Batteries included
Yes
Battery technology
Lithium-Manganese Dioxide (LiMnO2)
Battery type
CR2032
Battery weight
3 g
BIOS memory size
128 Mbit
BIOS type
UEFI AMI
Bundled software
Norton Internet Security (OEM version) LAN bandwidth management software
Cables included
SATA
Clear CMOS button
Yes
Clear CMOS jumper
Yes
Compatible processor series
Intel® Celeron®, Intel® Core™ i3, Intel® Core™ i5, Intel® Core™ i7, Intel® Core™ i9, Intel® Pentium® Gold
Component for
PC
Cooling type
Active
Country of origin
China
CPU fan connector
Yes
Depth
196 mm
Desktop Management Interface (DMI) version
2.7
DisplayPorts quantity
2
DVI-D ports quantity
1
ECC сompatibility
ECC & Non-ECC
EPS power connector (8-pin)
Yes
Ethernet interface type
Gigabit Ethernet
Ethernet LAN
Yes
Ethernet LAN (RJ-45) ports
1
Front panel audio connector
Yes
Front panel connector
Yes
Graphics card
HD Graphics
Graphics card family
Intel
HDCP
Yes
HDMI ports quantity
1
Headphone outputs
3
Height
35 mm
Lithium weight per battery
0.07 g
Maximum internal memory
96 GB
Maximum internal memory supported by processor
96 GB
Maximum resolution
4096 x 2304 pixels
Memory channels
Dual-channel
Memory slots type
DIMM
Microphone in
Yes
Motherboard chipset
Intel H610 Express
Motherboard chipset family
Intel
Motherboard form factor
micro ATX
Number of battery cells
1
Number of HDDs supported
1
Number of M.2 (M) slots
1
Number of memory slots
2
Number of SATA III connectors
4
Number of storage drives supported
5
Package depth
265 mm
Package height
54 mm
Package weight
694 g
Package width
265 mm
Parallel processing technology support
Not supported
PC health monitoring
Fan, Temperature, Voltage, Water cooling
PCI Express x1 slots
1
PCI Express x16 slots
1
Power source type
ATX
Processor manufacturer
Intel
Processor socket
LGA 1700
Product colour
Black
Products per shipping (inner) case
1 pc(s)
PS/2 ports quantity
1
RGB LED pin header
Yes
Serial port headers
1
Supported memory clock speed (max)
5600 MHz
Supported memory clock speeds
5600, 5200, 4800, 4400 MHz
Supported memory module capacities
1GB, 2GB, 4GB, 8GB, 12GB, 32GB, 48GB
Supported memory types
DDR5-SDRAM
Supported processor sockets
LGA 1700
Supported storage drive interfaces
M.2, SATA III
Supported storage drive types
HDD & SSD
System Management BIOS (SMBIOS) version
2.7
TPM connector
Yes
Unbuffered memory
Yes
USB 2.0 connectors
2
USB 2.0 ports quantity
4
USB 3.2 Gen 1 (3.1 Gen 1) connectors
1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
2
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity
0
USB 3.2 Gen 2 (3.1 Gen 2) connectors
0
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity
0
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity
0
USB connector type
USB Type-A
VGA (D-Sub) ports quantity
1
Warranty period
3 year(s)
Wi-Fi
No
Width
230 mm
Windows operating systems supported
Windows 10 x64, Windows 11 x64

Manual

Open Manual

Leaflet

Open Leaflet
