Motherboard GIGABYTE B650M GAMING WIFI6E, AMD B650, Socket AM5, Micro ATX

Motherboard GIGABYTE B650M GAMING WIFI6E, AMD B650, Socket AM5, Micro ATX
Motherboard GIGABYTE B650M GAMING WIFI6E, AMD B650, Socket AM5, Micro ATX
Motherboard GIGABYTE B650M GAMING WIFI6E, AMD B650, Socket AM5, Micro ATX
Motherboard GIGABYTE B650M GAMING WIFI6E, AMD B650, Socket AM5, Micro ATX
36 mo.
Motherboard GIGABYTE B650M GAMING WIFI6E, AMD B650, Socket AM5, Micro ATX
Motherboard GIGABYTE B650M GAMING WIFI6E, AMD B650, Socket AM5, Micro ATX
Motherboard GIGABYTE B650M GAMING WIFI6E, AMD B650, Socket AM5, Micro ATX
Motherboard GIGABYTE B650M GAMING WIFI6E, AMD B650, Socket AM5, Micro ATX
R2,544
GIGABYTE B650M GAMING WIFI6E is a Micro ATX motherboard designed for Socket AM5 AMD Ryzen 9000 Series processors. Built on the AMD B650 chipset, it supports up to 256 GB DDR5 memory across four DIMM slots and provides modern connectivity including Wi‑Fi 6E, 2.5 GbE LAN and USB 3.2 Gen 1. The board i... Read More
Stock 3 Code 31236 Brand GIGABYTE Model B650M GAMING WIFI6E Warranty 3 Years

Shipping & Returns

Estimated delivery Thursday, October 1
You will be kept updated through our detailed tracking system
Payment options
EFTPayFastBank CardSnapScanZapperGoogle PayApple PayMobicredMoreTymePay on Arrival

GIGABYTE B650M GAMING WIFI6E is a Micro ATX motherboard designed for Socket AM5 AMD Ryzen 9000 Series processors. Built on the AMD B650 chipset, it supports up to 256 GB DDR5 memory across four DIMM slots and provides modern connectivity including Wi‑Fi 6E, 2.5 GbE LAN and USB 3.2 Gen 1. The board includes one PCIe 4.0 M.2 slot, a PCIe x1 slot and a 5+2+2 VRM phase design for stable power delivery suitable for gaming and productivity systems.

Advantages

The motherboard combines DDR5 memory support up to 6400 MHz with a robust VRM layout to deliver reliable performance for CPU‑intensive tasks. Integrated Wi‑Fi 6E and 2.5 GbE LAN offer high‑speed network connectivity, while the PCIe 4.0 M.2 slot enables fast NVMe storage. Micro ATX form factor provides a compact footprint without sacrificing expansion options.

Suitable for

  • Gaming desktops requiring modern connectivity and high memory capacity
  • Content creation and productivity systems using AMD Ryzen 9000 Series CPUs
  • Compact PC builds where Micro ATX is preferred

Key specifications

  • Chipset: AMD B650
  • Socket: Socket AM5 (supports AMD Ryzen 9000 Series)
  • Form factor: Micro ATX
  • Memory: 4 x DDR5 DIMM slots, up to 256 GB, up to 6400 MHz
  • Storage: 1 x PCIe 4.0 M.2 slot
  • Expansion: 1 x PCIe x1 (Gen3) slot
  • Networking: Wi‑Fi 6E, 2.5 GbE LAN
  • USB: USB 3.2 Gen 1 support
  • VRM: 5+2+2 phase design
  • Weight: 0.72 kg
  • RAID support: 0, 1, 10

How to use

Install the motherboard into a compatible Micro ATX chassis and mount a supported Socket AM5 CPU following the CPU and cooler manufacturer instructions. Populate DDR5 DIMM slots in the recommended channel order when installing memory modules. Connect storage devices to the M.2 slot or available SATA ports, and attach power connectors from a suitable PSU. Install the latest BIOS and chipset drivers from GIGABYTE to ensure full compatibility and performance.

Recommendations

For stable operation under load, use a quality power supply and an adequate CPU cooler. Update BIOS before first use if necessary and enable XMP/EXPO profiles in BIOS to run memory at advertised speeds.
Key Highlights
  • AMD Socket AM5:Supports AMD Ryzen 7000 / Ryzen 8000 / Ryzen 9000 Series Processors
  • Unparalleled Performance:5+2+2 Phases Digital VRM Solution
  • Dual Channel DDR5:2*SMD DIMMs with AMD EXPO™ & Intel® XMP Memory Module Support
  • SuperSpeed Storage:PCIe 4.0 x4 M.2 Connector
  • EZ-Latch:PCIe x16 Slot with Quick Release Design
  • Fast Networks:2.5GbE LAN & Wi-Fi 6E 802.11ax
  • Extended Connectivity:HDMI , D-sub
  • Smart Fan 6:Features Multiple Temperature Sensors, Hybrid Fan Headers with FAN STOP
  • Q-Flash Plus:Update BIOS Without Installing the CPU, Memory and Graphics Card
  • AMD Socket AM5 AMD Ryzen 7000 Series, AMD Ryzen 8000 Series, AMD Ryzen 9000 Series
  • PC micro ATX AMD B650 7.1 channels
  • DDR5-SDRAM 4 DIMM Maximum internal memory: 256 GB
  • HDD & SSD M.2, SATA III RAID support Number of storage drives supported: 5
  • BIOS type: UEFI AMI 256 Mbit ACPI version: 5.0 Clear CMOS jumper
  • 2.5 Gigabit Ethernet Wi-Fi Wi-Fi 6E (802.11ax) Bluetooth 5.3
Specifications
1st M.2 highest PCI Express generation
4.0
1st M.2 largest key size
2580
ACPI version
5.0
Antenna included
Yes
ATX Power connector (24-pin)
Yes
Audio output channels
7.1 channels
Batteries included
Yes
Battery technology
Lithium-Manganese Dioxide (LiMnO2)
Battery type
CR2032
Battery weight
3 g
BIOS memory size
256 Mbit
BIOS type
UEFI AMI
Bluetooth
Yes
Bluetooth version
5.3
Bundled software
Norton® Internet Security (OEM version) LAN bandwidth management software
Clear CMOS jumper
Yes
Compatible processor series
AMD Ryzen 7000 Series, AMD Ryzen 8000 Series, AMD Ryzen 9000 Series
Component for
PC
Country of origin
China
CPU fan connector
Yes
Depth
225 mm
Desktop Management Interface (DMI) version
2.7
DVI-D ports quantity
0
ECC сompatibility
Non-ECC
EPS power connector (8-pin)
Yes
Ethernet interface type
2.5 Gigabit Ethernet
Ethernet LAN
Yes
Ethernet LAN (RJ-45) ports
1
Front panel audio connector
Yes
Front panel connector
Yes
HDCP
Yes
HDMI ports quantity
1
HDMI version
2.1
Headphone outputs
1
Height
35 mm
Line-in
Yes
Lithium weight per battery
0.07 g
Maximum internal memory
256 GB
Maximum internal memory per slot
64 GB
Maximum resolution
4096 x 2160 pixels
Memory channels
Dual-channel
Memory slots type
DIMM
Microphone in
Yes
Motherboard chipset
AMD B650
Motherboard chipset family
AMD
Motherboard form factor
micro ATX
Number of battery cells
1
Number of chassis fan connectors
2
Number of CPU fan connectors
1
Number of EPS power connectors (8-pin)
1
Number of HDDs supported
4
Number of M.2 (M) slots
1
Number of memory slots
4
Number of RGB LED pin headers
3
Number of SATA III connectors
4
Number of storage drives supported
5
Package depth
268 mm
Package height
68 mm
Package weight
1.21 kg
Package width
270 mm
Parallel processing technology support
Not supported
PC health monitoring
Fan, Temperature, Voltage
PCI Express x1 (Gen 3.x) slots
1
PCI Express x16 (Gen 4.x) slots
1
Power source type
ATX
Processor manufacturer
AMD
Processor socket
Socket AM5
Products per shipping (inner) case
1 pc(s)
PS/2 ports quantity
1
RAID levels
0, 1, 10
RAID support
Yes
RGB LED pin header
Yes
Screws included
Yes
Supported memory clock speed (max)
6400 MHz
Supported memory clock speeds
6400,6200,6000,5600,5200,4800,4400 MHz
Supported memory types
DDR5-SDRAM
Supported processor sockets
Socket AM5
Supported storage drive interfaces
M.2, SATA III
Supported storage drive types
HDD & SSD
System Management BIOS (SMBIOS) version
2.7
Top Wi-Fi standard
Wi-Fi 6E (802.11ax)
TPM connector
Yes
Unbuffered memory
Yes
USB 2.0 connectors
2
USB 2.0 ports quantity
4
USB 3.2 Gen 1 (3.1 Gen 1) connectors
1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
2
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity
0
USB 3.2 Gen 2 (3.1 Gen 2) connectors
0
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity
0
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity
0
VGA (D-Sub) ports quantity
1
Warranty period
3 year(s)
Weight
720 g
Wi-Fi
Yes
Wi-Fi standards
Wi-Fi 6E (802.11ax)
Width
240 mm
WiFi-AP antenna jack
2
Windows operating systems supported
Windows 10 x64, Windows 11
WLAN controller model
Realtek RTL8852CE

Manual

Open Manual

Leaflet

Open Leaflet
