The GIGABYTE B650 AERO G is an ATX motherboard based on the AMD B650 chipset with Socket AM5 support. Designed for PC builders using AMD Ryzen 7000, 8000 and 9000 series processors, it supports up to 256 GB DDR5 memory across four DIMM slots and offers modern connectivity including 2.5GbE LAN and Wi... Read More
Stock 3 Code 312523 Brand GIGABYTE Model B650 AERO G Warranty 3 Years

Shipping & Returns

Estimated delivery Thursday, October 1
You will be kept updated through our detailed tracking system
Payment options
EFTPayFastBank CardSnapScanZapperGoogle PayApple PayMobicredMoreTymePay on Arrival

The GIGABYTE B650 AERO G is an ATX motherboard based on the AMD B650 chipset with Socket AM5 support. Designed for PC builders using AMD Ryzen 7000, 8000 and 9000 series processors, it supports up to 256 GB DDR5 memory across four DIMM slots and offers modern connectivity including 2.5GbE LAN and Wi‑Fi 6E. Storage options include multiple M.2 slots with PCIe 5.0/4.0 support and compatibility with both SSD and HDD drives and RAID configurations.

Advantages

The B650 AERO G delivers a balance of performance and expandability through support for high-speed DDR5 memory (up to 8000 MHz potential overclocking), a PCIe 5.0 x16 slot for the latest graphics cards, and two PCIe 4.0 M.2 slots for fast NVMe storage. Integrated 2.5GbE and Wi‑Fi 6E provide robust networking options, while the ATX form factor and four memory slots allow versatile system builds and upgrades.

Suitable for

  • Gaming PCs requiring a modern AM5 platform
  • Content creators using high-bandwidth storage and memory
  • Workstations needing multiple storage devices and RAID
  • Upgradable desktop builds that require DDR5 support

Key specifications

  • Form factor: ATX
  • Chipset: AMD B650
  • Processor socket: Socket AM5 (supports AMD Ryzen 7000/8000/9000 series)
  • Memory: 4 x DDR5 DIMM slots, up to 256 GB
  • Memory speed: supports high-frequency DDR5 (up to 8000 MHz potential with appropriate modules and BIOS settings)
  • Expansion: 1 x PCIe 5.0 x16 slot, additional PCIe lanes for devices
  • Storage: 1 x PCIe 5.0 M.2 and 2 x PCIe 4.0 M.2 slots (as described in summary)
  • Networking: 2.5GbE LAN and Wi‑Fi 6E

How to use

Install the motherboard into an ATX-compatible case following standard anti-static precautions. Mount a compatible Socket AM5 CPU and attach a suitable cooling solution, insert DDR5 memory modules in the recommended DIMM slots, and connect storage devices to the available M.2 or SATA ports. Install a supported graphics card into the PCIe 5.0 x16 slot if required. Connect power supply cables to the 24-pin ATX and CPU power headers, then configure BIOS/UEFI settings to recognize installed memory, storage, and CPU. Update the firmware and install the latest drivers for networking and chipset components.

Recommendations

For stable operation and full performance, use high-quality DDR5 memory modules listed on the motherboard compatibility list (QVL), keep BIOS updated, and use a cooling solution rated for your chosen AMD Ryzen CPU. When configuring RAID or high-speed NVMe arrays, ensure your power supply and cooling meet the sustained load requirements.
Key Highlights
  • AMD Socket AM5: Supports AMD Ryzen 7000/ Ryzen 8000/ Ryzen 9000 Series Processors
  • VisionLINK: One USB-C Port for Video, Data Transfer and Charging
  • Dual Channel DDR5:4*DIMMs with AMD EXPO & Intel XMP Memory Module Support
  • Next Generation Storage:1*PCIe 5.0 x4 and 2*PCIe 4.0 x4 M.2 Connectors
  • Advanced Thermal Design & M.2 Thermal Guard III: To Ensure VRM Power Stability & 25110 PCIe 5.0 M.2 SSD Performance
  • EZ-Latch: PCIe x16 Slot & M.2 Connectors with Quick Release & Screwless Design
  • Fast Networks: Intel 2.5GbE LAN & Wi-Fi 6E 802.11ax
  • Extended Connectivity: DP IN, HDMI, Front USB-C 20Gbps Support and Upcoming GIGABYTE USB4 AIC Support
  • Smart Fan 6:Features Multiple Temperature Sensors, Hybrid Fan Headers with FAN STOP and Noise Detection
  • Q-Flash Plus:Update BIOS Without Installing the CPU, Memory and Graphics Card
  • AMD Socket AM5 AMD Ryzen 7000 Series, AMD Ryzen 8000 Series, AMD Ryzen 9000 Series
  • PC ATX AMD B650 7.1 channels
  • DDR5-SDRAM 4 DIMM Maximum internal memory: 256 GB
  • HDD & SSD M.2, SATA III RAID support Number of storage drives supported: 7
  • BIOS type: UEFI AMI 256 Mbit ACPI version: 5.0 Clear CMOS jumper
  • 2.5 Gigabit Ethernet Wi-Fi Wi-Fi 6E (802.11ax) Bluetooth 5.2
Specifications
12V power connector
Yes
1st M.2 highest PCI Express generation
5.0
1st M.2 largest key size
25110
2nd M.2 highest PCI Express generation
4.0
2nd M.2 largest key size
25110
3rd M.2 highest PCI Express generation
4.0
3rd M.2 largest key size
25110
ACPI version
5.0
Antenna included
Yes
ATX Power connector (24-pin)
Yes
Audio output channels
7.1 channels
Batteries included
Yes
Battery technology
Lithium-Manganese Dioxide (LiMnO2)
Battery type
CR2032
Battery weight
3 g
BIOS memory size
256 Mbit
BIOS type
UEFI AMI
Bluetooth
Yes
Bluetooth version
5.2
Bundled software
Norton® Internet Security (OEM version) LAN bandwidth management software
Clear CMOS jumper
Yes
Compatible processor series
AMD Ryzen 7000 Series, AMD Ryzen 8000 Series, AMD Ryzen 9000 Series
Component for
PC
Country of origin
China
CPU fan connector
Yes
Depth
244 mm
Desktop Management Interface (DMI) version
2.7
DirectX version
12.0
Discrete graphics support
Yes
DisplayPort version
1.4
DisplayPorts quantity
1
DVI-D ports quantity
0
ECC сompatibility
Non-ECC
EPS power connector (8-pin)
Yes
Ethernet interface type
2.5 Gigabit Ethernet
Ethernet LAN
Yes
Ethernet LAN (RJ-45) ports
1
Front panel audio connector
Yes
Front panel connector
Yes
HDCP
Yes
HDMI ports quantity
1
HDMI version
2.1
Height
35 mm
Line-in
Yes
Lithium weight per battery
0.07 g
Maximum internal memory
256 GB
Maximum internal memory per slot
64 GB
Maximum resolution
4096 x 2160 pixels
Memory channels
Dual-channel
Memory slots type
DIMM
Microphone in
Yes
Motherboard chipset
AMD B650
Motherboard chipset family
AMD
Motherboard form factor
ATX
Number of battery cells
1
Number of chassis fan connectors
6
Number of HDDs supported
4
Number of M.2 (M) slots
3
Number of memory slots
4
Number of RGB LED pin headers
5
Number of SATA III connectors
4
Number of storage drives supported
7
Number of temperature sensor headers
2
Number of water pump connectors
3
Package depth
270 mm
Package height
80 mm
Package weight
2.49 kg
Package width
335 mm
Parallel processing technology support
Not supported
PC health monitoring
Fan, Noise, Temperature, Voltage, Water cooling
PCI Express x16 (Gen 3.x) slots
1
PCI Express x16 (Gen 4.x) slots
2
Power source type
ATX
Processor manufacturer
AMD
Processor socket
Socket AM5
Product colour
Black
Products per shipping (inner) case
1 pc(s)
RAID levels
0, 1, 10
RAID support
Yes
RGB LED pin header
Yes
S/PDIF out port
Yes
Screws included
Yes
Serial port headers
1
Supported memory clock speed (max)
8000 MHz
Supported memory clock speeds
8000,7800,7600,7200,7000,6800,6666,6600,6400,6200,6000,5600,5200,4800,4400 MHz
Supported memory types
DDR5-SDRAM
Supported processor sockets
Socket AM5
Supported storage drive interfaces
M.2, SATA III
Supported storage drive types
HDD & SSD
System Management BIOS (SMBIOS) version
2.7
Top Wi-Fi standard
Wi-Fi 6E (802.11ax)
TPM connector
Yes
Unbuffered memory
Yes
USB 2.0 connectors
2
USB 2.0 ports quantity
2
USB 3.2 Gen 1 (3.1 Gen 1) connectors
1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
4
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity
0
USB 3.2 Gen 2 (3.1 Gen 2) connectors
0
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity
3
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity
1
USB 3.2 Gen 2x2 connectors
1
VGA (D-Sub) ports quantity
0
Warranty period
3 year(s)
Wi-Fi
Yes
Wi-Fi standards
802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax), Wi-Fi 6E (802.11ax)
Width
305 mm
WiFi-AP antenna jack
2
Windows operating systems supported
Windows 10 x64, Windows 11 x64
WLAN controller model
RZ616

Manual

Open Manual

Leaflet

Open Leaflet
