The GIGABYTE B550 EAGLE WIFI6 is an ATX motherboard for Socket AM4 systems, based on the AMD B550 chipset. It supports AMD Ryzen 5000 G-Series processors and up to 128 GB DDR4 memory across four DIMM slots. Designed for reliable high-performance desktop builds, the board includes dual M.2 slots (one... Read More
Stock 9 Code 111196 Brand GIGABYTE Model B550 EAGLE WIFI6 Warranty 3 Years

Shipping & Returns

Estimated delivery Thursday, October 1
You will be kept updated through our detailed tracking system
Payment options
EFTPayFastBank CardSnapScanZapperGoogle PayApple PayMobicredMoreTymePay on Arrival

The GIGABYTE B550 EAGLE WIFI6 is an ATX motherboard for Socket AM4 systems, based on the AMD B550 chipset. It supports AMD Ryzen 5000 G-Series processors and up to 128 GB DDR4 memory across four DIMM slots. Designed for reliable high-performance desktop builds, the board includes dual M.2 slots (one PCIe 4.0, one PCIe 3.0), integrated Wi‑Fi 6, multiple USB 3.2 Gen 2 ports and a robust 10+3+1 VRM phase design for stable power delivery.

Advantages

The motherboard combines a modern B550 platform with PCIe 4.0 storage support on one M.2 slot, integrated Wi‑Fi 6 connectivity and a strong VRM configuration to support sustained CPU performance. Its ATX form factor and multiple expansion slots provide flexibility for gaming, content creation or productivity systems while supporting up to 128 GB DDR4 memory at standard speeds.

Suitable for

  • Gaming PCs with mid-to-high performance AMD Ryzen CPUs
  • Content creation and video editing workstations
  • General-purpose desktop builds requiring Wi‑Fi connectivity
  • Upgradable systems that need multiple M.2 and PCIe expansion options

Key specifications

  • Form factor: ATX
  • Chipset: AMD B550
  • Socket: AM4 (supports AMD Ryzen 5000 G‑Series CPUs)
  • Memory: 4 × DDR4 DIMM slots, up to 128 GB, up to 3200 MHz (depending on CPU and configuration)
  • Storage: 2 × M.2 slots (1 × PCIe 4.0, 1 × PCIe 3.0)
  • Expansion: PCIe slots (multiple x1 Gen3 lanes)
  • Networking: Integrated Wi‑Fi 6
  • USB: USB 3.2 Gen 2 ports
  • VRM: 10+3+1 phase design
  • Weight: 1.25 kg

How to use

Install the GIGABYTE B550 EAGLE WIFI6 into a compatible ATX case and mount an AM4-supported AMD Ryzen 5000 G‑Series CPU on the socket following the motherboard and CPU manufacturer instructions. Insert DDR4 memory modules across the recommended DIMM slots to enable dual-channel operation. Connect storage devices to the SATA ports and M.2 slots as required, and attach power connectors from the PSU to the 24‑pin ATX and CPU power headers. Configure BIOS settings as needed for memory frequency, storage mode and boot order, then install your operating system and drivers, including chipset and Wi‑Fi drivers provided by GIGABYTE.

Recommendations

For stable performance, use a high-quality power supply and adequate case cooling. Populate memory modules in the slots recommended by the manual to enable optimal dual-channel operation, and install the latest BIOS and drivers from GIGABYTE for full compatibility with Ryzen 5000 series processors and Wi‑Fi 6 functionality.
Key Highlights
  • AMD Socket AM4: Supports AMD Ryzen 5000 / 4000 / 3000 Series Processors
  • Digital twin 10+3+1 phases VRM solution
  • Dual Channel DDR4: 4*DIMMs with AMD EXPO Memory Module Support
  • EZ-Latch: PCIe slots with Quick Release Design
  • Friendly UI: Multi-Theme, AIO Fan Control, and Q-Flash Auto Scan in BIOS and SW.
  • Ultra-Fast Storage: 2*M.2 slots, including PCIe 4.0 x1
  • Efficient Thermal: VRM Thermal Armor Advanced
  • Fast Networking: GbE LAN & Wi-Fi 6
  • Extended Connectivity: HDMI, Displayport
  • PCIe UD Slot: PCIe 4.0 x16 slots with 10X strength for graphics card & Better Heat dissipation effect
  • AMD Socket AM4 AMD Ryzen 3000 Series, AMD Ryzen 4000 Series, AMD Ryzen 5000 Series
  • PC ATX AMD B550 Realtek ALC897 7.1 channels
  • DDR4-SDRAM 4 DIMM Maximum internal memory: 128 GB
  • HDD & SSD M.2, PCI Express 4.0, SATA III RAID support Number of storage drives supported: 6
  • BIOS type: UEFI AMI 128 Mbit ACPI version: 5.0 Clear CMOS jumper
  • Gigabit Ethernet Wi-Fi Wi-Fi 6 (802.11ax) Bluetooth 5.3
Specifications
1st M.2 highest PCI Express generation
4.0
1st M.2 largest key size
22110
2nd M.2 highest PCI Express generation
3.0
2nd M.2 largest key size
22110
ACPI version
5.0
Antenna included
Yes
ATX Power connector (24-pin)
Yes
Audio chip
Realtek ALC897
Audio output channels
7.1 channels
Batteries included
Yes
Battery technology
Lithium-Manganese Dioxide (LiMnO2)
Battery type
CR2032
Battery weight
3 g
BIOS memory size
128 Mbit
BIOS type
UEFI AMI
Bluetooth
Yes
Bluetooth version
5.3
Bundled software
Norton® Internet Security (OEM version) LAN bandwidth management software
Clear CMOS jumper
Yes
Compatible processor series
AMD Ryzen 3000 Series, AMD Ryzen 4000 Series, AMD Ryzen 5000 Series
Component for
PC
Cooling type
Passive
CPU fan connector
Yes
Depth
244 mm
Desktop Management Interface (DMI) version
2.7
DirectX version
12.0
DVI-D ports quantity
0
ECC сompatibility
ECC & Non-ECC
EPS power connector (8-pin)
Yes
Ethernet interface type
Gigabit Ethernet
Ethernet LAN
Yes
Ethernet LAN (RJ-45) ports
1
Front panel audio connector
Yes
Front panel connector
Yes
HDCP
Yes
HDMI ports quantity
1
HDMI version
2.1
Headphone outputs
1
Height
35 mm
LAN controller
Realtek RTL8111H
Line-in
Yes
Lithium weight per battery
0.07 g
Maximum internal memory
128 GB
Maximum internal memory per slot
32 GB
Maximum resolution
4096 x 2160 pixels
Memory channels
Dual-channel
Memory slots type
DIMM
Microphone in
Yes
Motherboard chipset
AMD B550
Motherboard chipset family
AMD
Motherboard form factor
ATX
Number of battery cells
1
Number of chassis fan connectors
3
Number of CPU fan connectors
2
Number of EPS power connectors (8-pin)
1
Number of HDDs supported
4
Number of M.2 (M) slots
2
Number of memory slots
4
Number of RGB LED pin headers
5
Number of SATA III connectors
4
Number of storage drives supported
6
Number of water pump connectors
1
Package depth
270 mm
Package height
80 mm
Package weight
1.48 kg
Package width
335 mm
Parallel processing technology support
Not supported
PC health monitoring
Fan, Temperature, Voltage, Water cooling
PCI Express x1 (Gen 3.x) slots
4
PCI Express x16 (Gen 4.x) slots
1
Power source type
ATX
Processor manufacturer
AMD
Processor socket
Socket AM4
Product colour
Dark brown
Products per shipping (inner) case
1 pc(s)
RAID levels
0, 1, 10
RAID support
Yes
RGB LED pin header
Yes
Screws included
Yes
Supported memory clock speed (max)
3200 MHz
Supported memory clock speeds
3200,2933,2667,2400,2133 MHz
Supported memory types
DDR4-SDRAM
Supported processor sockets
Socket AM4
Supported storage drive interfaces
M.2, PCI Express 4.0, SATA III
Supported storage drive types
HDD & SSD
System Management BIOS (SMBIOS) version
2.7
Top Wi-Fi standard
Wi-Fi 6 (802.11ax)
TPM connector
Yes
Unbuffered memory
Yes
USB 2.0 connectors
2
USB 2.0 ports quantity
4
USB 3.2 Gen 1 (3.1 Gen 1) connectors
2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
2
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity
1
USB 3.2 Gen 2 (3.1 Gen 2) connectors
0
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity
1
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity
0
VGA (D-Sub) ports quantity
0
Warranty period
3 year(s)
Weight
1.25 kg
Wi-Fi
Yes
Wi-Fi standards
802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax)
Width
305 mm
WiFi-AP antenna jack
2
Windows operating systems supported
Windows 10 x64, Windows 11 x64
WLAN controller model
Realtek RTL8851BE
