Motherboard GIGABYTE B550 AORUS ELITE AX V2 ATX, AMD B550, Socket AM4, DDR4, 4 DIMM, Wi‑Fi 6E, 2.5Gb LAN

Motherboard GIGABYTE B550 AORUS ELITE AX V2 ATX, AMD B550, Socket AM4, DDR4, 4 DIMM, Wi‑Fi 6E, 2.5Gb LAN
Motherboard GIGABYTE B550 AORUS ELITE AX V2 ATX, AMD B550, Socket AM4, DDR4, 4 DIMM, Wi‑Fi 6E, 2.5Gb LAN
Motherboard GIGABYTE B550 AORUS ELITE AX V2 ATX, AMD B550, Socket AM4, DDR4, 4 DIMM, Wi‑Fi 6E, 2.5Gb LAN
Motherboard GIGABYTE B550 AORUS ELITE AX V2 ATX, AMD B550, Socket AM4, DDR4, 4 DIMM, Wi‑Fi 6E, 2.5Gb LAN
Motherboard GIGABYTE B550 AORUS ELITE AX V2 ATX, AMD B550, Socket AM4, DDR4, 4 DIMM, Wi‑Fi 6E, 2.5Gb LAN
36 mo.
Motherboard GIGABYTE B550 AORUS ELITE AX V2 ATX, AMD B550, Socket AM4, DDR4, 4 DIMM, Wi‑Fi 6E, 2.5Gb LAN
Motherboard GIGABYTE B550 AORUS ELITE AX V2 ATX, AMD B550, Socket AM4, DDR4, 4 DIMM, Wi‑Fi 6E, 2.5Gb LAN
Motherboard GIGABYTE B550 AORUS ELITE AX V2 ATX, AMD B550, Socket AM4, DDR4, 4 DIMM, Wi‑Fi 6E, 2.5Gb LAN
Motherboard GIGABYTE B550 AORUS ELITE AX V2 ATX, AMD B550, Socket AM4, DDR4, 4 DIMM, Wi‑Fi 6E, 2.5Gb LAN
Motherboard GIGABYTE B550 AORUS ELITE AX V2 ATX, AMD B550, Socket AM4, DDR4, 4 DIMM, Wi‑Fi 6E, 2.5Gb LAN
R3,277
The GIGABYTE B550 AORUS ELITE AX V2 is an ATX motherboard designed for Socket AM4 systems, based on the AMD B550 chipset. It supports AMD Ryzen 5000 Series processors and up to 128 GB DDR4 memory across four DIMM slots, with overclocking support up to 4733 MHz (OC). The board features a 12+2 phases ... Read More
Stock 30 Code 26626 Brand GIGABYTE Model B550 AORUS ELITE AX V2 Warranty 3 Years

Shipping & Returns

Estimated delivery Thursday, October 1
You will be kept updated through our detailed tracking system
Payment options
EFTPayFastBank CardSnapScanZapperGoogle PayApple PayMobicredMoreTymePay on Arrival

The GIGABYTE B550 AORUS ELITE AX V2 is an ATX motherboard designed for Socket AM4 systems, based on the AMD B550 chipset. It supports AMD Ryzen 5000 Series processors and up to 128 GB DDR4 memory across four DIMM slots, with overclocking support up to 4733 MHz (OC). The board features a 12+2 phases digital power design, dual PCIe 3.0 M.2 slots for high-speed NVMe storage, WiFi 6E wireless connectivity and 2.5GbE LAN for fast wired networks. This motherboard targets users who need stable performance and modern connectivity for gaming, content creation and general high-performance PC builds.

Advantages

The 12+2 phases digital power design provides stable power delivery for modern Ryzen CPUs, improving system reliability under load. Dual M.2 PCIe 3.0 slots allow installation of high-speed NVMe drives for faster boot and application load times. Integrated WiFi 6E and 2.5GbE LAN offer flexible high-bandwidth network options. Support for up to 128 GB DDR4 memory and multi-GPU/expansion support via ATX layout ensures versatility for gaming and productivity setups.

Suitable for

  • Gaming PCs with AMD Ryzen 5000 Series processors
  • Content creation and video editing workstations
  • High-performance home or office PCs requiring fast storage and networking

Key specifications

  • Form factor: ATX
  • Chipset: AMD B550
  • Processor socket: Socket AM4 (supports AMD Ryzen 5000 Series)
  • Memory: 4 x DDR4 DIMM slots, up to 128 GB, up to 4733 MHz (OC)
  • Power design: 12+2 phases digital VRM
  • Storage: 2 x PCIe 3.0 M.2 slots
  • Expansion: PCIe slots per ATX layout (see manufacturer for full slot configuration)
  • Networking: WiFi 6E, 2.5GbE LAN
  • Supported memory type: DDR4-SDRAM
  • Weight: 1.12 kg

How to use

Install the motherboard into a compatible ATX case and mount a Socket AM4-compatible Ryzen CPU following the CPU cooler and socket manufacturer instructions. Populate up to four DDR4 DIMMs, install NVMe drives into the M.2 slots, connect storage and power cables to the PSU, and attach front-panel connectors. Update the BIOS to the latest version for optimal Ryzen 5000 Series support and configure memory XMP/OC settings in BIOS if required. Install the latest drivers for chipset, LAN and WiFi after the operating system is set up.

Recommendations

Use a quality CPU cooler and a PSU with sufficient wattage; ensure BIOS is updated before installing a Ryzen 5000 Series CPU. For best networking performance enable WiFi 6E on compatible routers and use a 2.5GbE-capable switch or router to take advantage of faster wired LAN speeds.
Key Highlights
  • Supports AMD Ryzen 5000 Series/ Ryzen 5000 G-Series/ Ryzen 4000 G-Series/ Ryzen 3000 and Ryzen 3000 G-Series Processors
  • Dual Channel ECC/ Non-ECC Unbuffered DDR4, 4 DIMMs
  • 12+2 Phases Digital Twin Power Design with 50A DrMOS
  • Advanced Thermal Design with Enlarged Surface Heatsinks
  • Ultra Durable™ PCIe 4.0 x16 Slot
  • Dual Ultra-Fast NVMe PCIe 4.0/3.0 x4 M.2 with Dual Thermal Guards
  • Onboard WiFi 6E 802.11ax & BT 5.2
  • AMP-UP Audio with ALC1200 and WIMA Capacitors
  • Blazing Fast 2.5GbE LAN with Bandwidth Management
  • Front USB 3.2 Gen1 Type-C and DisplayPort & HDMI for Multiple Display
  • RGB FUSION 2.0 Supports Addressable LED & RGB LED Strips
  • Smart Fan 5 Features Multiple Temperature Sensors, Hybrid Fan Headers with FAN STOP
  • Q-Flash Plus Update BIOS without Installing the CPU, Memory and Graphics Card
  • Pre-installed IO Shield for Easy and Quick Installation
  • AMD Socket AM4 AMD Ryzen 3000 Series, AMD Ryzen 4000 Series, AMD Ryzen 5000 Series
  • PC ATX AMD B550 Realtek ALC897 7.1 channels
  • DDR4-SDRAM 4 DIMM Maximum internal memory: 128 GB
  • HDD & SSD M.2, SATA III RAID support Number of storage drives supported: 6
  • BIOS type: UEFI AMI 128 Mbit ACPI version: 5.0 Clear CMOS jumper
  • 2.5 Gigabit Ethernet, Fast Ethernet, Gigabit Ethernet Wi-Fi Wi-Fi 6E (802.11ax) Bluetooth 5.3
Specifications
12V power connector
Yes
1st M.2 highest PCI Express generation
4.0
1st M.2 largest key size
22110
2nd M.2 highest PCI Express generation
3.0
2nd M.2 largest key size
22110
ACPI version
5.0
Antenna included
Yes
ATX Power connector (24-pin)
Yes
Audio chip
Realtek ALC897
Audio output channels
7.1 channels
Batteries included
Yes
Battery technology
Lithium-Manganese Dioxide (LiMnO2)
Battery type
CR2032
Battery weight
3 g
BIOS memory size
128 Mbit
BIOS type
UEFI AMI
Bluetooth
Yes
Bluetooth version
5.3
Bundled software
Norton® Internet Security (OEM version) LAN bandwidth management software
Clear CMOS jumper
Yes
Compatible processor series
AMD Ryzen 3000 Series, AMD Ryzen 4000 Series, AMD Ryzen 5000 Series
Component for
PC
Cooling type
Passive
Country of origin
China
CPU fan connector
Yes
Depth
244 mm
Desktop Management Interface (DMI) version
2.7
DirectX version
12.0
DisplayPort version
1.4
DisplayPorts quantity
1
DVI-D ports quantity
0
ECC сompatibility
ECC & Non-ECC
EPS power connector (8-pin)
Yes
Ethernet interface type
2.5 Gigabit Ethernet, Fast Ethernet, Gigabit Ethernet
Ethernet LAN
Yes
Ethernet LAN (RJ-45) ports
1
Front panel audio connector
Yes
Front panel connector
Yes
HDCP
Yes
HDMI ports quantity
1
HDMI version
2.1
Headphone outputs
1
Height
35 mm
LAN controller
Realtek RTL8125
Line-in
Yes
Lithium weight per battery
0.07 g
Maximum internal memory
128 GB
Maximum internal memory per slot
32 GB
Maximum number of SMP processors
1
Maximum resolution
5120 x 2880 pixels
Memory channels
Dual-channel
Memory slots type
DIMM
Microphone in
Yes
Motherboard chipset
AMD B550
Motherboard chipset family
AMD
Motherboard form factor
ATX
Number of battery cells
1
Number of chassis fan connectors
3
Number of CPU fan connectors
1
Number of EPS power connectors (8-pin)
1
Number of HDDs supported
4
Number of M.2 (M) slots
2
Number of memory slots
4
Number of RGB LED pin headers
5
Number of SATA III connectors
4
Number of storage drives supported
6
Number of water pump connectors
4
Package depth
270 mm
Package height
80 mm
Package weight
1.89 kg
Package width
335 mm
Parallel processing technology support
Not supported
PC health monitoring
Fan, Temperature, Voltage, Water cooling
PCI Express x1 (Gen 3.x) slots
1
PCI Express x16 (Gen 3.x) slots
2
PCI Express x16 (Gen 4.x) slots
1
Power source type
ATX
Processor manufacturer
AMD
Processor socket
Socket AM4
Product colour
Black
Products per shipping (inner) case
1 pc(s)
RAID levels
0, 1, 10
RAID support
Yes
RGB LED pin header
Yes
S/PDIF out port
Yes
Screws included
Yes
Supported memory clock speed (max)
4733 MHz
Supported memory clock speeds
4733,4600,4400,4266,4133,4000,3866,3733,3600,3466,3400,3200,2933,2667,2400,2133 MHz
Supported memory types
DDR4-SDRAM
Supported processor sockets
Socket AM4
Supported storage drive interfaces
M.2, SATA III
Supported storage drive types
HDD & SSD
System Management BIOS (SMBIOS) version
2.7
Top Wi-Fi standard
Wi-Fi 6E (802.11ax)
TPM connector
Yes
Unbuffered memory
Yes
USB 2.0 connectors
2
USB 2.0 ports quantity
2
USB 3.2 Gen 1 (3.1 Gen 1) connectors
2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
3
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity
0
USB 3.2 Gen 2 (3.1 Gen 2) connectors
0
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity
2
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity
0
VGA (D-Sub) ports quantity
0
Warranty period
3 year(s)
Weight
1.12 kg
Wi-Fi
Yes
Wi-Fi standards
802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax), Wi-Fi 6E (802.11ax)
Width
305 mm
WiFi-AP antenna jack
2
Windows operating systems supported
Windows 10 x64, Windows 11 x64
WLAN controller model
Intel Wi-Fi 6E AX210

Manual

Open Manual

Leaflet

Open Leaflet
