Finisar FTRJ1319P1BTL Compatible BlueOptics SFP BO05C13640D - 1.25 Gbps, 1310 nm, 10 km, LC Duplex, SMF

The BlueOptics BO05C13640D is a high-performance SFP transceiver designed to be fully compatible with the Finisar FTRJ1319P1BTL. It delivers reliable 1.25 Gbps data transmission over single-mode fiber at 1310 nm wavelength, supporting distances up to 10 km. This hot-pluggable module features LC duplex connector and digital diagnostic monitoring (DDM) for real-time performance tracking. Ideal for Gigabit Ethernet 1000BASE-LX/LH applications in data centers, enterprise networks, and telecommunications.

Advantages

Cost-effective alternative to OEM modules without compromising quality or performance. Fully MSA compliant and rigorously tested for seamless integration. Low power consumption (<1 W) and extended MTBF (>500,000 hours) ensure long-term reliability.

Suitable for

• Gigabit Ethernet 1000BASE-LX/LH connections
• Data center interconnects
• Enterprise network switches and routers
• Telecommunications equipment

Key specifications

• Form Factor: SFP
• Data Rate: 1.25 Gbps
• Wavelength: 1310 nm
• Max Distance: 10 km
• Fiber Type: Single-Mode Fiber (SMF)
• Connector: LC Duplex
• DDM/DOM: Yes
• Compatibility: Finisar FTRJ1319P1BTL
• Protocol: 1000BASE-LX/LH
• Hot-Pluggable: Yes
• Supply Voltage: 3.3 V
• Power Consumption: <1 W
• Operating Temperature: 0°C to 70°C
• Laser Type: DFB
• Transmit Power: -3 to 0 dBm
• Receiver Sensitivity: -23 dBm
• Standards: MSA, RoHS, CE, FCC
• MTBF: >500,000 hours

Recommendations

For optimal performance, use with single-mode fiber patch cables (LC duplex) and ensure proper handling to avoid damage to the optical ports. Compatible with any SFP slot supporting MSA standard.
