Fiber optic transceiver module BlueOptics X6539-R6-BO SFP+ LC Aluminium 20g

The BlueOptics X6539-R6-BO SFP+ LC Aluminium 20g is a fiber optic transceiver module designed for 10G optical links using an LC duplex connector and single-mode fiber. Constructed with an aluminium housing and weighing approximately 20 g, this SFP+ module implements 10GBASE-LR optics with 1310 nm transmit and receive wavelengths to support long-reach data transmission over single-mode fiber. The module follows MSA SFP+ mechanical and electrical form factors and includes digital diagnostics monitoring (DDM/DOM) functionality where supported by host hardware.

Advantages

The module provides 10 Gbit/s data transfer capability with LC duplex connectivity and an aluminium housing that aids heat dissipation and mechanical robustness. Compliance with industry MSA standards ensures interoperability with SFP+-compatible ports that accept 10GBASE-LR optics. Built-in digital diagnostics monitoring offers real-time information on parameters such as supply voltage, laser current, optical output and received power, and temperature when the host supports DDM/DOM.

Suitable for

Key specifications

How to use

Install the BlueOptics X6539-R6-BO into an SFP+ slot on compatible network equipment until it clicks into place, then connect an LC duplex single-mode fiber patch cord between transceivers or to a patch panel. Ensure the host device supports 10GBASE-LR optics and, if digital diagnostics are required, verify that DDM/DOM is enabled in the equipment. After insertion, confirm link status and negotiate speed per the switch or router interface. Follow standard electrostatic discharge (ESD) precautions during handling and keep transceiver dust caps on unused connectors.

Recommendations

To achieve reliable long-reach performance, use single-mode fiber cabling with appropriate LC duplex connectors and verify fiber end-face cleanliness before mating. Confirm compatibility with your specific hardware model and firmware, and consult vendor documentation when enabling DDM/DOM features. Store unused modules in anti-static packaging and avoid exposing the optical ports to dust or moisture.
