Extralink LC/UPC to LC/UPC Patch Cord, Multimode OM4 Duplex, 1m, LSZH, Aqua

The Extralink LC/UPC to LC/UPC Patch Cord is a high-performance multimode fiber optic cable designed for reliable data transmission in demanding network environments. With OM4 grade fiber and duplex configuration, this patch cord supports high-bandwidth applications up to 100GbE, making it ideal for data centers, LAN, and SAN infrastructures.

Advantages

This patch cord offers low insertion loss (≤0.3 dB) and high return loss (≥30 dB), ensuring minimal signal degradation and reliable performance. The LSZH (Low Smoke Zero Halogen) jacket provides enhanced safety in confined spaces, while the aqua color allows for easy identification. The 2.0 mm per strand cable diameter offers flexibility and durability for structured cabling.

Suitable for

• Data center interconnects
• Local Area Networks (LAN)
• Storage Area Networks (SAN)
• High-speed Ethernet applications (10GbE, 40GbE, 100GbE)

Key specifications

• Connector Type: LC/UPC to LC/UPC
• Fiber Mode: Multimode
• Fiber Grade: OM4
• Cable Configuration: Duplex
• Cable Length: 1 Meter
• Core/Cladding Diameter: 50/125 µm
• Jacket Material: LSZH
• Jacket Color: Aqua
• Insertion Loss: ≤ 0.3 dB
• Return Loss: ≥ 30 dB
• Bandwidth (850nm): 4700 MHz·km
• Bandwidth (1300nm): 500 MHz·km
• Operating Wavelengths: 850nm, 1300nm
• Cable Diameter: 2.0 mm (per strand)
• Operating Temperature: -20°C to 70°C
• Compliance: RoHS, CE

Recommendations

For optimal performance, ensure connectors are clean before installation. This patch cord is compatible with standard LC duplex interfaces and is suitable for use with OM4 transceivers.
