EXSYS EX-6074-3 Gigabit Ethernet PCIe x1 Network Interface Card, Low Profile, RJ45, Realtek RTL8111G

Many modern compact desktops and servers lack a reliable wired network connection, limiting speed and stability for demanding tasks. The EXSYS EX-6074-3 solves this by adding a dedicated Gigabit Ethernet port through a PCI Express x1 slot, ensuring fast and stable network access without relying on Wi-Fi.

Who is it for

This network card is ideal for system builders, IT administrators, and home users who need to upgrade a desktop, workstation, or small server with dependable wired networking. It is especially useful for low-profile or small form factor cases, as it includes both standard and low-profile brackets.

Main features

• Gigabit Ethernet (10/100/1000 Mbps) for high-speed wired connectivity
• PCI Express x1 interface compatible with PCIe 1.1 and newer slots
• Realtek RTL8111G chipset for broad OS support and reliable performance
• Supports Wake-on-LAN and PXE boot for remote management and deployment
• Includes low-profile bracket for installation in slim or compact cases
• LED indicators for link and activity status

Specifications

• Host Interface: PCI Express x1
• Expansion Card Standard: PCIe 1.1
• Network Interface: Gigabit Ethernet
• Data Transfer Rate: 10/100/1000 Mbps
• Number of Ports: 1 x RJ-45
• Chipset: Realtek RTL8111G
• Network Standards: IEEE 802.3, 802.3u, 802.3ab
• Flow Control: IEEE 802.3x
• VLAN Support: IEEE 802.1Q
• Full Duplex Support: Yes
• Jumbo Frame Support: Up to 9 KB
• Wake-on-LAN: Yes
• PXE Boot Support: Yes
• LED Indicators: Link/Activity
• Operating System Compatibility: Windows (XP/Vista/7/8/10/11, Server), Linux, macOS
• Form Factor: Low Profile (with included bracket)
• Certifications: CE, FCC

Tips

Before installation, ensure your motherboard has an available PCIe x1 slot. For low-profile cases, swap the standard bracket with the included low-profile bracket. Download the latest driver from the Realtek website for optimal performance and compatibility.
