EXSYS EX-47960 RS-232 to RJ-45 Serial Adapter, DB9 Male to RJ-45 Female, Straight-Through Pinout, Black

Legacy RS-232 equipment often lacks the modular connectivity needed for modern network infrastructure, leaving technicians wrestling with custom cables and unreliable connections. The EXSYS EX-47960 solves this by adapting a standard DB9 serial port to an RJ-45 jack, enabling the use of common twisted-pair cabling for console access and serial device extension.

Who is it for

Network administrators, field service engineers, and integrators who need to connect Cisco consoles, routers, switches, or other RS-232 devices to structured cabling systems. Ideal for those who prefer the convenience and low cost of RJ-45 patch cables over dedicated serial cables.

Main features

• Converts a DB9 male RS-232 port to an RJ-45 female jack
• Straight-through 1:1 pinout for transparent signal mapping
• Supports standard RS-232 data rates up to 115.2 kbps
• Compact, durable plastic housing with a black finish
• Plug-and-play – no drivers or external power required

Specifications

• Product type: Serial adapter
• Connector 1: DB9 male
• Connector 2: RJ-45 female
• Pinout: 1:1 straight-through
• Supported standard: EIA/TIA RS-232
• Data rate: Up to 115.2 kbps
• Housing material: Plastic
• Colour: Black
• Compatibility: Universal RS-232 devices, commonly used with Cisco console cables

Tips

Pair this adapter with a standard straight-through Ethernet patch cable to create a cost-effective console cable for Cisco equipment. For best results, keep total cable length under 15 metres to maintain signal integrity at high baud rates.
