Equip Cat.6 S/FTP Patch Cable, 20m, Yellow, 20 m, Cat6, S/FTP (S-STP), RJ-45, RJ-45, Yellow

Equip Cat.6 S/FTP Patch Cable, 20m, Yellow, 20 m, Cat6, S/FTP (S-STP), RJ-45, RJ-45, Yellow
Equip Cat.6 S/FTP Patch Cable, 20m, Yellow, 20 m, Cat6, S/FTP (S-STP), RJ-45, RJ-45, Yellow
Equip Cat.6 S/FTP Patch Cable, 20m, Yellow, 20 m, Cat6, S/FTP (S-STP), RJ-45, RJ-45, Yellow
Equip Cat.6 S/FTP Patch Cable, 20m, Yellow, 20 m, Cat6, S/FTP (S-STP), RJ-45, RJ-45, Yellow
Equip Cat.6 S/FTP Patch Cable, 20m, Yellow, 20 m, Cat6, S/FTP (S-STP), RJ-45, RJ-45, Yellow
Equip Cat.6 S/FTP Patch Cable, 20m, Yellow, 20 m, Cat6, S/FTP (S-STP), RJ-45, RJ-45, Yellow
R670
The equip® Cat.6 S/FTP Patch Cord is composed of high-quality materials and fully-examined to conform with industrial standards. Offering higher bandwidth and better signal-to-noise margin, the Cat.6 cable is able to deliver ultrahigh and error-free performance in the most demanding network environm... Read More
Stock 10 Code 2186089 Brand EQUIP Model 605569 Warranty 2 Years

Shipping & Returns

Estimated delivery Thursday, October 8
You will be kept updated through our detailed tracking system
Payment options
EFTPayFastBank CardSnapScanZapperGoogle PayApple PayMobicredMoreTymePay on Arrival
The equip® Cat.6 S/FTP Patch Cord is composed of high-quality materials and fully-examined to conform with industrial standards. Offering higher bandwidth and better signal-to-noise margin, the Cat.6 cable is able to deliver ultrahigh and error-free performance in the most demanding network environments.

Equip Cat.6 S/FTP Patch Cable, 20m, Yellow. Cable length: 20 m, Cable standard: Cat6, Cable shielding: S/FTP (S-STP), Connector 1: RJ-45, Connector 2: RJ-45, Connector contacts plating: Gold, Data transfer rate: 1000 Mbit/s, Product colour: Yellow

Key Highlights
  • 4 x 2 AWG 28/7
  • 250MHz performance Bandwidth
  • Suitable for PoE, PoE+
  • Stranded bare copper conductor
  • Foil and braid shield Reduces EMI/RFI interference
  • PIMF (Pairs in metal Foil)
  • Molded boot with Strain relief
  • RoHS compliant
  • Low Smoke Zero Halogen (LSZH/LSOH)
  • Compliant with ISO/IEC 11801 and EN 50173
  • 20 m
  • RJ-45 Straight Male
  • RJ-45 Straight Male
  • Cat6 S/FTP (S-STP)
  • Fast Ethernet, Gigabit Ethernet 1000 Mbit/s
  • Power over Ethernet (PoE) Plug and Play
  • Yellow
Specifications
AWG wire size
28/7
Cable length
20 m
Cable shape
Round
Cable shielding
S/FTP (S-STP)
Cable standard
Cat6
Cabling technology
10/100/1000Base-T(X)
Certification
ISO/IEC 11801, EN50288, TIA/EIA 568-C.2
Compliance certificates
CE, REACH, RoHS, UKCA
Conductor material
Copper
Conductor type
Stranded
Connector 1
RJ-45
Connector 1 form factor
Straight
Connector 1 gender
Male
Connector 2
RJ-45
Connector 2 form factor
Straight
Connector 2 gender
Male
Connector contacts plating
Gold
Country of origin
China
Data transfer rate
1000 Mbit/s
Depth
11.7 mm
Doesn't contain
Halogen
Ethernet interface type
Fast Ethernet, Gigabit Ethernet
Frequency
250 MHz
Harmonized System (HS) code
84733080
Height
20000 mm
Jacket material
Low smoke zero halogen (LSZH)
Master (outer) case gross weight
15.9 kg
Master (outer) case height
380 mm
Master (outer) case length
350 mm
Master (outer) case width
290 mm
Molded cable boot
Yes
Networking standards
IEEE 802.3, IEEE 802.5
Outer diameter
5.8 mm
Package depth
50 mm
Package height
290 mm
Package weight
350 g
Package width
250 mm
Plug and Play
Yes
Power over Ethernet (PoE)
Yes
Power over Ethernet (PoE) type supported
PoE+
Product colour
Yellow
Products per master (outer) case
22 pc(s)
Quantity per pack
1 pc(s)
Sustainability compliance
Yes
Weight
745 g
Width
8.34 mm

Document

Open Document

Leaflet

Open Leaflet
Price history over the last 6 months
Equip Cat.6 S/FTP Patch Cable, 20m, Yellow, 20 m, Cat6, S/FTP (S-STP), RJ-45, RJ-45, Yellow
Current
R670
Lowest
R531
Highest
R702
Change 24H
+R65   +11%
Week
+R72   +12%
Month
+R70   +12%
