EPRADO-R19-27U/600-BLUE 27U 19-Inch Wall Mount Rack Cabinet, Blue, 600x600x1300 mm

The EPRADO-R19-27U/600-BLUE is a high-quality 27U wall mount rack cabinet designed for secure and organized installation of 19-inch network and server equipment. Constructed from cold-rolled steel with a durable powder-coated blue finish, this rack offers reliable performance and a professional appearance. It features a tempered glass front door with lock, removable lockable side panels, and a solid rear panel for enhanced security. The cabinet includes two pairs of adjustable mounting rails, passive ventilation via perforated top and bottom panels, and cable entry points with brush strips for efficient cable management. With a static load capacity of 60 kg and IP20 protection rating, it is ideal for IT rooms, offices, and data centers.

Advantages

Robust cold-rolled steel construction ensures long-lasting durability. The tempered glass door allows easy monitoring of equipment while maintaining security. Adjustable mounting rails accommodate various equipment depths. Passive ventilation helps dissipate heat without active cooling. Cable entry points with brush strips keep cables organized and dust-free. The blue color adds a distinctive look to your installation.

Suitable for

• Network switches, patch panels, and routers
• Server and storage equipment
• Audio/video systems
• Telecommunications installations
• Small to medium-sized IT environments

Key specifications

• Rack Standard: 19-inch
• Rack Units: 27U
• Mounting Type: Wall Mount
• External Dimensions (WxDxH): 600 x 600 x 1300 mm
• Internal Usable Depth: 550 mm
• Material: Cold-Rolled Steel
• Front Door: Tempered Glass with Lock
• Side Panels: Removable, Lockable
• Rear Panel: Solid
• Color: Blue
• Static Load Capacity: 60 kg
• Ventilation: Passive (perforated top/bottom)
• Cable Entry: Top and Bottom with Brush Strips
• Mounting Rails: 2 pairs, adjustable depth
• IP Protection Rating: IP20
• Finish: Powder Coated
• Compliance: RoHS, CE
• Assembly: Fully Assembled

Recommendations

For optimal performance, ensure the wall mount is securely anchored to a load-bearing wall. Use appropriate cable management accessories to maintain airflow and organization. This cabinet is designed for indoor use only.
