EFB Elektronik LC/APC Simplex Fiber Adapter White

The EFB Elektronik LC/APC Simplex Fiber Adapter is a high-quality network coupler designed for single-mode fiber optic connections. Featuring LC/APC connectors on both sides, this adapter ensures low insertion loss and high return loss, making it ideal for critical network infrastructure. The white plastic housing with ceramic sleeve provides durability and reliable performance in patch panels, wall outlets, and distribution boxes.

Advantages

This adapter offers exceptional signal integrity with typical insertion loss below 0.2 dB and return loss greater than 60 dB. The angled physical contact (APC) polish minimizes back reflection, ensuring stable data transmission. With over 500 mating cycles, it provides long-lasting reliability. The snap-in panel mount design allows for easy installation in standard cutouts.

Suitable for

• Fiber optic patch panels
• Wall outlets
• Distribution boxes
• FTTH (Fiber to the Home) applications
• Data center cabling

Key specifications

• Connector Type: LC/APC to LC/APC
• Fiber Mode: Single Mode (OS1, OS2)
• Adapter Type: Simplex
• Sleeve Material: Ceramic
• Housing Material: Plastic (ABS)
• Color: White
• Insertion Loss: < 0.2 dB typical
• Return Loss: > 60 dB typical
• Mating Cycles: > 500
• Operating Temperature: -20°C to +70°C
• Storage Temperature: -40°C to +85°C
• Compliance: RoHS, REACH
• Standard: IEC 61754-20
• Mounting Type: Snap-in / Panel Mount
• Dust Caps: Included

Recommendations

For optimal performance, use with single-mode patch cables and ensure clean connections. The included dust caps protect the adapter when not in use.
