EFB Elektronik ECOFIBER Fiber Optic Patch Cable LC/UPC to LC/UPC Duplex OM3 1m LSZH Aqua

The EFB Elektronik ECOFIBER fiber optic patch cable is a high-performance duplex multimode cable designed for reliable data transmission in data centers, LANs, and SANs. With LC/UPC connectors on both ends, OM3 fiber class, and a 1-meter length, this cable supports high-bandwidth applications up to 10 Gbps and beyond. The LSZH (Low Smoke Zero Halogen) jacket ensures safety in enclosed spaces, while the aqua color provides easy identification.

Advantages

This cable offers low insertion loss (≤0.3 dB) and high return loss (≥30 dB), ensuring minimal signal degradation. The duplex design allows for simultaneous bidirectional communication, and the 50/125 µm core/cladding is optimized for OM3 performance. The LSZH jacket reduces toxic fumes in case of fire, making it ideal for use in offices, data centers, and public buildings.

Suitable for

• Data center cabling infrastructure
• Local Area Networks (LAN)
• Storage Area Networks (SAN)
• High-speed fiber optic connections

Key specifications

• Product Type: Fiber Optic Patch Cable
• Connector Type A: LC/UPC
• Connector Type B: LC/UPC
• Fiber Mode: Multi-Mode
• Fiber Class: OM3
• Core Diameter: 50 µm
• Cladding Diameter: 125 µm
• Cable Length: 1 m
• Jacket Material: LSZH (Low Smoke Zero Halogen)
• Jacket Color: Aqua
• Number of Fibers: 2
• Cable Diameter: 3.0 mm
• Insertion Loss (max): ≤ 0.3 dB
• Return Loss (min): ≥ 30 dB
• Bandwidth @ 850nm: 1500 MHz-km
• Bandwidth @ 1300nm: 500 MHz-km
• Operating Temperature: -20°C to 70°C
• Standards Compliance: IEC 60793-2-10 Type A1a.2, TIA/EIA-492AAAC

Recommendations

For optimal performance, ensure connectors are clean before installation. This cable is compatible with all standard LC interfaces and is suitable for use with 10GBASE-SR, 40GBASE-SR4, and 100GBASE-SR10 applications.
