EFB ELEKTRONIK 53705.4V2B2 DIN Rail Front Panel Empty 1.7mm 12x SC-Simplex / LC-Duplex / E2000

For network installers who need a clean, professional finish on DIN rail fiber optic distribution boxes, this EFB ELEKTRONIK front panel delivers a precision-cut steel faceplate with twelve adapter cutouts. Unlike generic blanking plates, it is pre-punched for SC-Simplex, LC-Duplex and E2000 couplings, so you can populate exactly the adapters your project requires without drilling or filing.

Highlights

• 1.7 mm steel construction for lasting rigidity and EMI shielding
• 12 adapter cutouts: SC-Simplex, LC-Duplex, E2000 compatible
• Empty panel – fit only the adapters you actually need
• Light grey RAL 7035 finish matches standard DIN rail enclosures
• RoHS and REACH compliant

In daily use

The panel mounts internally to the DIN rail enclosure, keeping fiber connections recessed and protected. Its slim 1.7 mm profile adds minimal depth, while the pre-formed cutouts accept snap-in adapters for quick assembly. Because it ships without adapters, you avoid paying for unused ports and can standardize on one panel across mixed SC, LC and E2000 installations.

Full specifications

• Product type: Front panel for DIN rail fiber optic distribution boxes
• Material: Steel
• Panel thickness: 1.7 mm
• Number of adapter cutouts: 12
• Compatible adapter types: SC-Simplex, LC-Duplex, E2000
• Panel status: Empty (no adapters included)
• Colour: Grey (RAL 7035)
• Mounting type: Internal to DIN rail enclosure
• Environmental compliance: RoHS, REACH
• Dimensions (H x W x D): 120 x 30 x 1.7 mm
• Weight: 0.05 kg

Final note

Choose this panel when you want a single, cost-effective front plate for multiple connector types in DIN rail fiber optic distribution – no adapter waste, no modification needed.
