Dome IP security camera Hikvision DS-2CD2345G0P-I — Indoor, 4 MP (2688×1520), 1.68 mm fixed lens, 360° rotation, ceiling/wall mount, wired

The Dome IP security camera Hikvision DS-2CD2345G0P-I is a wired indoor surveillance device offering 4 MP resolution (2688×1520) with a 1.68 mm fixed lens and a 360° rotation mechanism for flexible coverage. Designed for ceiling or wall mounting, the camera delivers up to 30 fps video using a CMOS sensor and is intended for monitoring retail, office or residential spaces where a compact white dome form factor is preferred.

Advantages

This Hikvision dome camera combines a high-resolution 4 MP sensor with a very wide field of view provided by the 1.68 mm fixed lens and a 360° rotation range, enabling broad area coverage from a single mounting point. The wired Ethernet connectivity offers reliable network transmission and steady power options in appropriate installations. The compact white housing and ceiling/wall mount compatibility simplify installation in indoor environments while maintaining a discreet appearance.

Suitable for

• Retail stores and point-of-sale monitoring
• Office interiors, corridors and meeting rooms
• Residential common areas such as hallways and entryways
• Indoor spaces requiring wide coverage from a single camera

When it may not be suitable

This camera is designed specifically for indoor use and wired installations; it is not suitable for outdoor installations where weatherproofing and environmental protection are required. Environments that require optical zoom, very long-range viewing or extremely low-light performance beyond the listed specifications may need a different camera model.

Key specifications

• Image sensor type: CMOS
• Maximum resolution: 4 MP (2688 × 1520)
• Lens: 1.68 mm fixed focal length
• Rotation range: 360°
• Viewing angles: 180° horizontal, 101° vertical
• Frame rate: up to 30 fps
• Connectivity: wired Ethernet LAN
• Placement: indoor
• Mounting options: ceiling or wall
• Color: white
• Weight: 0.52 kg

How to use

Install the camera on a ceiling or wall using the supplied mounting hardware and ensure the mounting surface can support the device weight. Connect the camera to your network via Ethernet; if Power over Ethernet (PoE) is available on your network switch or injector, use it to supply power and data over a single cable. Configure network settings, video encoding (H.265+ recommended if compatible), resolution and frame rate through the camera web interface or compatible NVR/software. Position the lens and set the rotation to cover the desired area, then verify image framing, focus and recording settings in live view.

What to consider before purchase

• Intended placement is indoor only; this model is not rated for outdoor use.
• Requires wired Ethernet connectivity; no built-in Wi‑Fi.
• Fixed lens with very wide angle; no optical zoom available.
• Confirm compatibility with your NVR or video management software and preferred video codec.
• Check whether Power over Ethernet (PoE) is available if you prefer single-cable installation.

Recommendations

For best results, mount the camera centrally in the area to be monitored to take advantage of the wide-angle lens and 360° rotation. Use wired Ethernet with PoE where possible for reliable power and network connectivity, and configure motion detection and recording schedules in your VMS to reduce storage use while capturing relevant events.
