Digitus Pre-assembled Fiberglass Universal Breakout Cable, Single Mode OS2, 12 Fibers, LC/UPC - LC/UPC

Digitus Pre-assembled Fiberglass Universal Breakout Cable, Single Mode OS2, 12 Fibers, LC/UPC - LC/UPC
Digitus Pre-assembled Fiberglass Universal Breakout Cable, Single Mode OS2, 12 Fibers, LC/UPC - LC/UPC
Digitus Pre-assembled Fiberglass Universal Breakout Cable, Single Mode OS2, 12 Fibers, LC/UPC - LC/UPC
Digitus Pre-assembled Fiberglass Universal Breakout Cable, Single Mode OS2, 12 Fibers, LC/UPC - LC/UPC
Digitus Pre-assembled Fiberglass Universal Breakout Cable, Single Mode OS2, 12 Fibers, LC/UPC - LC/UPC
Digitus Pre-assembled Fiberglass Universal Breakout Cable, Single Mode OS2, 12 Fibers, LC/UPC - LC/UPC
Digitus Pre-assembled Fiberglass Universal Breakout Cable, Single Mode OS2, 12 Fibers, LC/UPC - LC/UPC
Digitus Pre-assembled Fiberglass Universal Breakout Cable, Single Mode OS2, 12 Fibers, LC/UPC - LC/UPC
Digitus Pre-assembled Fiberglass Universal Breakout Cable, Single Mode OS2, 12 Fibers, LC/UPC - LC/UPC
Digitus Pre-assembled Fiberglass Universal Breakout Cable, Single Mode OS2, 12 Fibers, LC/UPC - LC/UPC
R2,633
Digitus Pre-assembled Fiberglass Universal Breakout Cable, Single Mode OS2, 12 Fibers, LC/UPC - LC/UPC. Cable length: 30 m, Cable type: U-DQ(ZN) BH, Fibre optic type: OS2, Connector 1: LC, Connector 2: LC, Core diameter: 9 µmKey FeaturesCable type : Breakout/ universal cable (I/A-DQ (ZN) BH X E 9/12... Read More
Stock Out Of StockNo Stock Code 2553874 Brand DIGITUS Model DK-2A33CU030BK-BBB Warranty 2 Years

Shipping & Returns

Digitus Pre-assembled Fiberglass Universal Breakout Cable, Single Mode OS2, 12 Fibers, LC/UPC - LC/UPC. Cable length: 30 m, Cable type: U-DQ(ZN) BH, Fibre optic type: OS2, Connector 1: LC, Connector 2: LC, Core diameter: 9 µm

Key Features

  • Cable type : Breakout/ universal cable (I/A-DQ (ZN) BH X E 9/125µm)
  • Fiber category : Singlemode
  • Fiber type : OS2 G.657.A1 9/125
  • Number of cores : 12
  • Length : 30
  • Plug connection 1 : LC/UPC
  • Plug connection 2 : LC/UPC
  • Sheath material : Dca
  • Color outer jacket : Black
  • Halogen-free (according to EN 50267-2-3) : Yes
  • IL for multimode: max. 0.3dB
  • IL for singlemode: max.0.3dB
  • RL for multimode: min. 30dB
  • RL for singlemode: min. 50dB
  • Outer diameter of the black protective tube: 30.5 mm
  • Outer cable diameter: 6.0 mm
  • Operating temperature: -20~70℃
  • Storage temperature: -20~70℃
  • Outer diameter of the ring band: 35 mm
  • Pull-in aid on both sides
  • Protection tube: 28.5 mm
  • U-DQ(ZN) BH OS2
  • 30 m
  • LC Male
  • LC Male
  • Connector polish type: UPC
  • Jacket material: Low smoke zero halogen (LSZH)
  • Single-mode
  • Black
Pre-assembled fiber optic breakout cables enable simple, time-saving and flexible installation of high-bandwidth network links.

- Pre-assembled
- High-quality connectors fitted ex works
- Ready for immediate use, without additional splicing work
- Standard lengths available from stock
- High-quality components and construction
- Applications Applicable for indoor and outdoor use
- Connection of network cabinets without potential differences
- Individual mechanically protected fibers
- Robust cable construction
- Pull-in aid on both sides for secure installation

This pre-terminated breakout fiber optic cable is ideal for installations that require an extremely robust and reliable fiber optic cable design where maximum mechanical protection is required. It offers a secure plug & play solution for installations through the pre-terminated connectors. It is easy to install on partially assembled patch panels, for example. The supplied measurement protocol eliminates the need for time-consuming follow-up checks.
Key Highlights
  • Cable type : Breakout/ universal cable (I/A-DQ (ZN) BH X E 9/125µm)
  • Fiber category : Singlemode
  • Fiber type : OS2 G.657.A1 9/125
  • Number of cores : 12
  • Length : 30
  • Plug connection 1 : LC/UPC
  • Plug connection 2 : LC/UPC
  • Sheath material : Dca
  • Color outer jacket : Black
  • Halogen-free (according to EN 50267-2-3) : Yes
  • IL for multimode: max. 0.3dB
  • IL for singlemode: max.0.3dB
  • RL for multimode: min. 30dB
  • RL for singlemode: min. 50dB
  • Outer diameter of the black protective tube: 30.5 mm
  • Outer cable diameter: 6.0 mm
  • Operating temperature: -20~70℃
  • Storage temperature: -20~70℃
  • Outer diameter of the ring band: 35 mm
  • Pull-in aid on both sides
  • Protection tube: 28.5 mm
  • U-DQ(ZN) BH OS2
  • 30 m
  • LC Male
  • Connector polish type: UPC
  • Jacket material: Low smoke zero halogen (LSZH)
  • Single-mode
  • Black
Specifications
Cable length
30 m
Cable type
U-DQ(ZN) BH
Cladding diameter
125 µm
Connector 1
LC
Connector 1 gender
Male
Connector 2
LC
Connector 2 gender
Male
Connector polish type
UPC
Core diameter
9 µm
Country of origin
China
Fiber mode structure
Single-mode
Fibre optic type
OS2
Full duplex
Yes
Insertion loss
0.3 dB
Jacket material
Low smoke zero halogen (LSZH)
Number of optical fibres
12
Operating temperature (T-T)
-20 - 70
Package depth
360 mm
Package volume
23328 cm³
Package weight
2750 g
Package width
360 mm
Plug and Play
Yes
Product colour
Black
Quantity per pack
1 pc(s)
Return loss
50 dB
Storage temperature (T-T)
-20 - 70
UK Trade Tariff code
85447000

Leaflet

Open Leaflet
