DIGITUS IT BASIC PDU. Vertical. 32A. 24 x C13. 4 x C19 IT BASIC PDU. Vertical. 32A. 24 x C13. 4 x C19

Safe and professional power distribution unit designed for demanding IT environments and installation in 19" network and server racks. The DIGITUS® PDU provides reliable distribution of mains power through a combination of C13 and C19 outputs with integrated extraction protection at each socket. This vertical 28-outlet PDU is engineered for up to 8,000 W (250 V AC / 32 A) and offers compact space usage to preserve rack units for other equipment.

Advantages

The unit is optimized for 19" rack mounting and vertical installation to save rack space. Individual C13 and C19 outlets include integrated extraction protection to prevent accidental unplugging of standard cables. The PDU delivers consistent and reliable power distribution suitable for networks, server cabinets and laboratory setups.

Key specifications

• Mounting: 19" rack, vertical installation
• Number of outlets: 28 (combination of C13 and C19)
• Maximum output: 8,000 W
• Voltage / Current: 250 V AC / 32 A
• Extraction protection: integrated at each C13 and C19 output

How to use

Install the PDU vertically in a compatible 19" rack and secure it according to rack manufacturer instructions. Connect the mains supply capable of delivering up to 32 A at 250 V AC. Plug IT devices into the C13 and C19 outlets while ensuring the integrated extraction protection is properly engaged to avoid accidental disconnection. Monitor load to keep total consumption within the 8,000 W rating.

Recommendations

Use appropriate cable management and ensure the rack power feed and circuit protection are rated for 32 A. Verify cable compatibility with C13/C19 connectors and distribute load among outlets to avoid overloading a single circuit.
