DIGITUS installation cable - Cat 7 - S/FTP - AWG 23/1 - simplex - 250m - Orange - 1200 MHz Dca (EN 50575), Paper box,SX

DIGITUS installation cable - Cat 7 - S/FTP - AWG 23/1 - simplex - 250m - Orange - 1200 MHz Dca (EN 50575), Paper box,SX
DIGITUS installation cable - Cat 7 - S/FTP - AWG 23/1 - simplex - 250m - Orange - 1200 MHz Dca (EN 50575), Paper box,SX
DIGITUS installation cable - Cat 7 - S/FTP - AWG 23/1 - simplex - 250m - Orange - 1200 MHz Dca (EN 50575), Paper box,SX
DIGITUS installation cable - Cat 7 - S/FTP - AWG 23/1 - simplex - 250m - Orange - 1200 MHz Dca (EN 50575), Paper box,SX
DIGITUS installation cable - Cat 7 - S/FTP - AWG 23/1 - simplex - 250m - Orange - 1200 MHz Dca (EN 50575), Paper box,SX
DIGITUS installation cable - Cat 7 - S/FTP - AWG 23/1 - simplex - 250m - Orange - 1200 MHz Dca (EN 50575), Paper box,SX
R5,405
Future-oriented standards and high-end quality for your network.- 10GBit Ethernet- 1200 MHz transmission frequency- Permanent Link certified- PoE, PoE+, 4PPoE (IEEE 802.3af;3at;3bt)- BauPVO class Dca-s2 d1 a1The Digitus® Cat.7 S/FTP installation cable is characterized by the following cable structur... Read More
Stock 3 Code 114290 Brand DIGITUS Model DK-1743-VH-250 Warranty 2 Years

Shipping & Returns

Estimated delivery Friday, October 2
You will be kept updated through our detailed tracking system
Payment options
EFTPayFastBank CardSnapScanZapperGoogle PayApple PayMobicredMoreTymePay on Arrival

Future-oriented standards and high-end quality for your network.

- 10GBit Ethernet
- 1200 MHz transmission frequency
- Permanent Link certified
- PoE, PoE+, 4PPoE (IEEE 802.3af;3at;3bt)
- BauPVO class Dca-s2 d1 a1

The Digitus® Cat.7 S/FTP installation cable is characterized by the following cable structure 4x2x AWG23/1 and achieves a transmission frequency of up to 1200 MHz. The halogen-free cable sheath conforms to the IEC 60332-3-24, FRNC-C, LSZH-3 and BauPVO Euroclass Dca standards. The cable is suitable for structured building cabling in secondary and tertiary areas. Conforms to the standards ISO/IEC 11801, DIN EN 50173, DIN EN 50288-4-1.

Key Highlights
  • Conductor: Bare copper wire, AWG 23/1
  • System(s) of assessment and verification of constancy of performance: System 3
  • Insulation: SFS-PE (foamed polyethylene jacket)
  • Total number of insulated conductors: 8, twisted into 4 pairs
  • Color code: Blue-white, orange-white, green-white, brown-white
  • Shielding of the individual pairs: aluminum-laminated polyester film, covers 100%
  • Overall shielding: copper braiding
  • Outer sheath: Eca to B2ca in accordance with EN 50575; LSZH
  • Outer sheath thickness (nominal): 0.50 mm (Eca); 0.52 mm (Dca); 0.60 mm (Cca); 0.60 (B2ca)
  • Color: Orange (RAL 2008)
  • Mechanical properties:
  • Strain relief: 150N max.
  • Dynamic bending radius: 8x AD mm min.
  • Static bending radius: 4x AD mm min.
  • Transport and storage temperature range: -20 °C to +75 °C
  • Operating temperature range: -20 °C to +50 °C
  • Installation temperature range: 0 °C to +50 °C
  • Outer diameter simplex (nominal): 7.0 mm (Eca); 7.2 mm (Dca); 7.5 mm (Cca); 7.5 mm (B2ca)
  • Weight (kg/km): 49.5 kg (Eca); 51 kg (Dca), 53 kg (Cca); 53 kg (B2ca)
  • Electrical properties:
  • Impedance: 100±15 Ohm @ 4 - 1000 MHz; 100±25 OHM @ 100-600 MHz
  • Capacitance: 45pF/m nom. at 1KHz
  • Capacitance: 40 pF/m nominal @ 1 KHz
  • Insulation resistance: 5 GOhm x km min.
  • DC resistance: 95 Ohm/km max. (2% max. unbalanced resistance)
  • Loop resistance: 190 Ohm/km max. (2% max. unbalanced resistance)
  • Operating voltage: 72 Vdc max.
  • Coupling attenuation: CA-Type 1b
  • Phase delay: 450 nS/100 m max.
  • Time delay: 10 nS/100 m max.
  • Separation class: "d" according to EN 50174-2
  • NVP: 79%
Specifications
AWG wire size
23/1
Cable class
F
Cable length
250 m
Cable shape
Round
Cable shielding
S/FTP (S-STP)
Cable standard
Cat7
Cabling technology
10GBase-T
Certification
CPR class Dca
Conductor material
Copper
Conductor type
Solid
Connector 1
No
Connector 1 gender
No
Connector 2
No
Connector 2 gender
No
Country of origin
China
Ethernet interface type
2.5 Gigabit Ethernet, 10 Gigabit Ethernet, 5 Gigabit Ethernet, Fast Ethernet, Gigabit Ethernet
Frequency
1200 MHz
Harmonized System (HS) code
84733080
Jacket material
Low smoke zero halogen (LSZH)
Networking standards
IEEE 802.3an
Operating temperature (T-T)
-20 - 50 °C
Package depth
400 mm
Package type
Box
Package volume
48000 cm³
Package weight
15.2 kg
Package width
400 mm
Plug and Play
Yes
Product colour
Orange
Quantity per pack
1 pc(s)
Storage temperature (T-T)
-20 - 75 °C
UK Trade Tariff code
85444920

Leaflet

Open Leaflet
