DIGITUS installation cable - Cat 5e - U-UTP - 305m - Grey

DIGITUS installation cable - Cat 5e - U-UTP - 305m - Grey
DIGITUS installation cable - Cat 5e - U-UTP - 305m - Grey
DIGITUS installation cable - Cat 5e - U-UTP - 305m - Grey
DIGITUS installation cable - Cat 5e - U-UTP - 305m - Grey
R2,307
ASSNET installation cables guarantee outstanding performance and connection quality for your network- 1GBit Ethernet- 100 MHz transmission frequency- BauPVO Class EcaThe ASSNET100 Cat.5e U/UTP installation cable is characterized by the following cable structure 4x2x AWG 23/1 CCA cores and achieves a... Read More
Stock 1 Code 129316 Brand DIGITUS Model ACU-4511-305 Warranty 2 Years

Shipping & Returns

Estimated delivery Thursday, October 1
You will be kept updated through our detailed tracking system
Payment options
EFTPayFastBank CardSnapScanZapperGoogle PayApple PayMobicredMoreTymePay on Arrival

ASSNET installation cables guarantee outstanding performance and connection quality for your network

- 1GBit Ethernet
- 100 MHz transmission frequency
- BauPVO Class Eca

The ASSNET100 Cat.5e U/UTP installation cable is characterized by the following cable structure 4x2x AWG 23/1 CCA cores and achieves a transmission frequency of up to 100 MHz. The PVC cable sheath conforms to BauPVO Euroclass Eca. The cable is suitable for structured building cabling in secondary and tertiary areas.

Key Highlights
  • Physical properties:
  • Conductor: Copper-clad aluminum, AWG 23/1
  • Total number of insulated conductors: 8, twisted into 4 pairs
  • Color code: Blue-white, orange-white, green-white, brown-white
  • Shielding of the individual pairs: None
  • Overall shielding: None
  • Outer sheath thickness (nominal): 0.50 mm nominal
  • Mechanical properties:
  • Strain relief: 150N max.
  • Dynamic bending radius: 8x AD mm min.
  • Static bending radius: 4x AD mm min.
  • Transport and storage temperature range: -20 °C to +75 °C
  • Operating temperature range: -20 °C to +60 °C
  • Installation temperature range: 0 °C to +50 °C
  • Electrical properties:
  • Impedance: 100±15 Ohm @ 1-100 MHz
  • Capacitance: 40 pF/m nominal @ 800 Hz
  • Capacitance unbalance (pair-earth): 1.5 pF/m max. @ 1 KHz
  • Insulation resistance: 2 GOhm x km min.
  • Loop resistance: 262 Ohm/km max. (2% max. unbalanced resistance)
  • Operating voltage: 72 Vdc max.
  • Coupling attenuation: CA-Type 3
  • Phase delay: 535 nS/100 m max.
  • Time delay: 20 nS/100 m max.
  • Isolation class: "b" according to EN 50174-2
  • Maximum insert length: 60 m
  • NVP: 69%
Specifications
AWG wire size
24/1
Cable diameter
5 mm
Cable length
305 m
Cable shielding
U/UTP (UTP)
Cable standard
Cat5e
Certification
CPR class Eca
Conductor type
Solid
Connector 1
No
Connector 1 gender
No
Connector 2
No
Connector 2 gender
No
Country of origin
China
Harmonized System (HS) code
84733080
Input impedance
100 O
Insulation outer diameter
0.5 mm
Jacket material
Polyvinyl chloride (PVC)
Operating temperature (T-T)
-20 - 75 °C
Package depth
200 mm
Package volume
24850 cm³
Package weight
7.6 kg
Package width
350 mm
Product colour
Grey
Storage temperature (T-T)
-20 - 60 °C
UK Trade Tariff code
85444920

Leaflet

Open Leaflet
