DEDRA DED7817 Manual Tile Cutter 600 mm Cutting Length with Tungsten Carbide Wheel

The DEDRA DED7817 manual tile cutter delivers clean, precise cuts up to 600 mm in ceramic, porcelain, and stoneware tiles. Its robust steel base with anti-slip rubber pads keeps the tool steady, while the twin chrome-plated guide bars and ball-bearing slide ensure smooth, accurate scoring every time.

Advantages

The tungsten carbide cutting wheel, coated with titanium nitride for extra hardness, scores even dense porcelain with minimal effort. An adjustable angle guide allows straight and diagonal cuts, and the single-point breaker snaps tiles cleanly along the scored line. The ergonomic rubberized handle reduces hand fatigue during extended use, and the replaceable cutting wheel extends the tool's service life.

Suitable for

• Ceramic wall and floor tiles
• Porcelain tiles up to 16 mm thick
• Stoneware tiles
• Straight and diagonal cuts
• Professional tilers and DIY home renovation

Key specifications

• Max cutting length: 600 mm
• Max tile thickness: 16 mm
• Cutting wheel diameter: 22 mm
• Cutting wheel bore: 6 mm
• Blade material: Tungsten carbide with TiN coating
• Guide bars: 2 chrome-plated steel bars with ball bearings
• Base: Steel with rubber anti-slip pads
• Breaking mechanism: Single point breaker
• Angle guide: Adjustable for diagonal cuts
• Ruler: Metric scale
• Handle: Ergonomic rubberized grip
• Cutting wheel: Replaceable

Recommendations

For best results, score the tile with a single firm pass, then apply even pressure on the breaker handle. Replace the cutting wheel when cuts become rough or require extra force. Keep the guide bars clean and lightly lubricated to maintain smooth sliding action.
