Composite Switch EUROLITE AVS-802 8-channel 2U rackmount

EUROLITE AVS-802 Composite Switch is an 8-channel composite video switch in a 2U rackmount housing designed for manual selection between up to eight analog video sources. The unit fits a standard 19" rack and is intended for monitoring, event production and AV installations that require switching of composite video signals while keeping a compact footprint for straightforward installation and cable management.

Advantages

The AVS-802 offers eight composite inputs with a single selectable output in a 2U chassis, enabling quick manual switching without the need for complex control systems. Its rackmount format simplifies integration into existing AV racks, and the straightforward analog connections ensure compatibility with legacy composite video equipment.

Suitable for

Key specifications

How to use

Mount the AVS-802 into a standard 19" rack using appropriate screws. Connect up to eight composite video sources to the input RCA connectors and connect the output to a monitor, recorder or downstream device. Use the front-panel selector or switch controls to choose the desired input for the output. Ensure all connected equipment is powered and use proper cable routing to avoid interference.

Recommendations

For best results, use quality shielded RCA cables and avoid running composite cables alongside power lines to reduce interference. When integrating with modern digital systems, consider using appropriate converters or digitizers for improved signal processing.
