Miniature Circuit Breaker HiSmart NV821488 2P 10A Class C

Miniature Circuit Breaker HiSmart NV821488 2P 10A Class C is a compact DIN-rail mounted protective device designed to interrupt electrical circuits in case of overloads and short circuits. The two-pole breaker is suitable for single-phase or split-phase applications up to AC 400 V and provides a rated breaking capacity of 6 kA with Class C tripping characteristic for moderate inrush currents.

Advantages

The device offers overload and short-circuit protection with clear contact position indication (red = closed, green = open). It features an anti-mistake contact terminal block, flame-retardant housing with high temperature and impact resistance, and dual-sided top and bottom connections for flexible wiring. The breaker meets IEC/EN 60898-1 standards and includes a clip-on mounting for 35 mm DIN rails.

Suitable for

• Residential distribution boards
• Small commercial electrical panels
• Protection of lighting and outlet circuits
• DIN-rail switchgear assemblies

Key specifications

• Number of poles: 2
• Rated current (In): 10 A
• Tripping class: C
• Rated voltage (Ue): AC 400 V
• Insulation voltage (Ui): 500 V
• Rated frequency: 50/60 Hz
• Rated breaking capacity (Icu): 6000 A
• Rated impulse withstand voltage (Uimp): 6000 V
• Mechanical life: 20,000 operations
• Electrical life: 8,000 operations
• Protection degree: IP20
• Terminal type: cable / pin-type busbar
• Wire / busbar cross-section: up to 25 mm² / 18-3 AWG
• Connection: top and bottom
• Mounting: 35 mm DIN rail (EN 60715) with fast clip
• Operating temperature: -5 °C to +40 °C (daily average <35 °C)
• Storage temperature: -25 °C to +70 °C
• Dimensions: 85.5 × 78.8 × 36 mm
• Standards: IEC 60898-1 / EN 60898-1

How to use

Install the HiSmart NV821488 on a 35 mm EN 60715 DIN rail using the built-in fast clip. Connect incoming and outgoing conductors to the top and bottom terminals according to local wiring practices, observing the terminal markings and using appropriate cable or busbar sizes up to 25 mm². Ensure the supply is de-energized before installation and perform wiring torque checks. After installation, verify the contact position indicator to confirm the breaker state.

Recommendations

Use this 2P 10A Class C miniature circuit breaker for protecting residential and light-commercial circuits with moderate inrush currents. Do not exceed the rated current and breaking capacity; follow local electrical codes and have installations performed or inspected by a qualified electrician.
