CLUB3D CAC-1083 DisplayPort cable 2 m HDMI Type D (Micro) Black

The Club 3D CAC-1083 is a 2 m DisplayPort 1.4 to HDMI 4K60Hz cable with an HDMI Type D (Micro) male connector. It provides a wired conversion from a DisplayPort source to an HDMI display or projector and supports HDR and deep color playback when used with compatible devices. The cable is black, weighs 68 g and is CE, FCC and RoHS compliant.

Advantages

The cable supports DisplayPort 1.4 receiver rates up to 5.4 Gbps per lane across four lanes and delivers HDMI output fully compliant with the HDMI specification. It supports UHD resolutions up to 4096 x 2160 at 60 Hz and multiple video color formats (RGB/YCbCr) with color depths up to 12 bits per channel when the available link bandwidth permits. HDR video with deep color at 4K 60Hz is supported when both source and display are HDR-capable.

Suitable for

• Connecting a DisplayPort 1.4 source (e.g., laptop or graphics card) to an HDMI-equipped monitor or projector
• Transmitting 4K 60Hz video content with HDR and high color depth (when devices support it)
• Use with devices that include HDMI Type D (Micro) inputs

Key specifications

• Cable length: 2 m
• Connector 1: HDMI Type D (Micro) male
• Interface: DisplayPort 1.4 (source) to HDMI output
• Maximum resolution: up to 4096 x 2160 @ 60 Hz
• Color formats: RGB / YCbCr; color depth up to 12 bpc (subject to link bandwidth)
• HDR support: Yes (requires DP 1.4 source and HDR-capable display)
• Product colour: Black
• Weight: 0.068 kg
• Certifications: CE, FCC, RoHS

How to use

Connect the DisplayPort source device to the cable’s DisplayPort end and plug the HDMI Type D (Micro) connector into the display or projector’s HDMI input. Ensure both source and display are powered on. Configure the source’s display output settings to the desired resolution and refresh rate (for example, 3840 x 2160 or 4096 x 2160 at 60 Hz). If HDR and deep color are required, enable HDR output in the source system settings and verify the display supports HDR.

Recommendations

For HDR and 12 bpc deep color at 4K 60Hz, use a source device that supports DisplayPort 1.4 and enable HDR in both source and display settings. Performance and color depth depend on the total available link bandwidth and the capabilities of connected devices.
