CHARGE AMPS Charge Controller/Charger DC-DC SRNE 12V 20A 300W

The CHARGE AMPS Charge Controller/Charger DC-DC SRNE is a high-efficiency DC-DC battery charger designed for 12V systems in RVs, caravans, marine, and off-grid vehicles. It converts input voltage from 9-16V DC to a regulated 12V output, delivering up to 20A (300W) to charge and maintain auxiliary batteries. With support for multiple battery chemistries and intelligent multi-stage charging, this unit ensures optimal battery health and performance.

Advantages

This charger features >97% efficiency, reducing energy loss and heat generation. Its compact design with intelligent fan cooling allows for reliable operation in temperatures from -35°C to +65°C. The common negative grounding simplifies installation, while comprehensive protection (input over/under voltage, output over voltage, over temperature, reverse polarity, output short circuit) safeguards your system.

Suitable for

• RVs and caravans
• Marine applications
• Off-grid vehicle systems
• 12V auxiliary battery charging

Key specifications

• Input Voltage Range: 9-16V DC
• Output Voltage: 12V DC
• Max Output Current: 20A
• Max Input Power: 300W
• Battery Types: LiFePO4, AGM, Gel, Flooded Lead-Acid
• Charging Algorithm: Multi-stage (Boost, Float, Equalization for Lead-Acid; CC/CV for LiFePO4)
• Efficiency: >97%
• No-load Current: <100mA
• Operating Temperature: -35°C to +65°C
• Protection: Input Over/Under Voltage, Output Over Voltage, Over Temperature, Reverse Polarity, Output Short Circuit
• Grounding: Common Negative
• IP Rating: IP32
• Cooling: Intelligent Fan Cooling
• Max Cable Size: 10 AWG / 6mm²

Recommendations

For best results, use with appropriate gauge wiring and ensure proper ventilation. Compatible with 12V lead-acid and LiFePO4 batteries. Always follow manufacturer guidelines for installation and battery selection.
